Parts for Lg DLEX4070W: Panel Drawer Assembly And Guide Assembly Parts

This water tank assembly holds and delivers chilled water to the dispenser and ice system, restoring proper water flow and preventing dispenser dry-running. Direct-fit replacement designed to match the original reservoir's form and function. What it does

• Stores and supplies water for the refrigerator dispenser and ice-making components.
• Replaces cracked or damaged reservoirs that cause leaks or loss of water supply.
• Helps resolve intermittent or no-water dispense when the tank is compromised.
• Works with the refrigerator's fill and drain pathways to maintain correct water levels.

• One water tank assembly

• Disconnect power and shut off the water supply before servicing.
• Drain remaining water from the lines and tank to avoid spills during removal.
• Handle the tank carefully to avoid damaging fittings or mounting tabs.
• After installation, restore water and power, then check connections and test for leaks and proper dispense/ice fill.

This balance weight is the washer counterweight that helps stabilize the tub during spin cycles to reduce vibration and noise. Replaces a worn or damaged weight to restore smoother, quieter operation. What it does:

• Counterbalances the washer drum to minimize shaking and excessive movement during spin cycles
• Helps prevent banging or knocking noises caused by an unbalanced tub
• Supports even load distribution to reduce stress on suspension components
• Used when a cracked, loose, or missing weight is causing vibration issues

• One balance weight (counterweight)

• Disconnect power and water supply before starting any repair
• Support the tub or cabinet when removing/installing the weight to avoid sudden movement
• Tighten mounting hardware to OEM torque if specified; use the factory fasteners when available

This is a taptite screw used to fasten components to sheet metal or plastic in your appliance. It forms its own threads as it's driven, helping secure panels, brackets, or covers that have lost or stripped fasteners.

• Provides secure fastening in pre-formed or unthreaded holes
• Helps fix loose, rattling, or misaligned panels and covers
• Commonly used for mounting small brackets and internal trim
• Useful when an original screw is missing or stripped

• Unplug the appliance or shut off power and any water supply before service
• Keep track of screw length and location; replace like-for-like
• Start by hand to avoid cross-threading; do not overtighten
• If the original hole is damaged, assess for safe re-use or repair

This taptite screw fastens panels and internal components in your appliance. It forms its own threads as it's driven to create a secure hold, restoring proper fit and reducing rattles caused by loose or missing fasteners.

• Forms threads in the mating material for a tight, secure fit
• Secures covers, brackets, and assemblies during repair or reassembly
• Replace when the original screw is missing, rusted, stripped, or won't tighten
• Helps address loose or rattling panels and misaligned parts

• Disconnect power before servicing
• Start the screw by hand to avoid cross-threading; use the correct driver
• Do not overtighten; if the receiving hole is damaged, repair or replace the mating component
• Reuse any original washers/spacers in the same order if present

The Lint Filter Duct Cover is an OEM part for LG dryers. It is designed to fit over the lint filter and duct area, ensuring that lint is properly trapped and does not escape into the dryer’s internal components. This cover helps maintain efficient airflow and prevents potential lint buildup, which can be a fire hazard. This part measures approximately 11-1/2 inches by 1-1/4 inches.

You should replace the lint filter duct cover if it becomes damaged or cracked, or if it fails to stay securely in place. Common causes of a bad lint filter duct cover include regular wear and tear, accidental damage during cleaning or maintenance, or exposure to high heat that can warp the plastic.

Symptoms of a bad lint filter duct cover include:

• Lint escaping into the dryer drum
• The cover not fitting securely over the lint filter
• Increased drying times due to reduced airflow
• Visible cracks or damage to the cover

This OEM LG part is also compatible with Sears/Kenmore models.

This distortion spring applies the correct tension within the dryer mechanism so parts return to position and operate smoothly. Replacing a fatigued or broken spring helps prevent loose movement, rattling, and inconsistent operation of the related assembly. What it does

• Provides the designed return/tension force for the associated dryer mechanism
• Helps maintain alignment and smooth movement of moving parts
• Can reduce rattling or squeaking caused by weak or missing spring tension
• Symptoms include components not returning to position or intermittent operation

• One distortion spring

• Disconnect power; for gas dryers, also shut off the gas supply
• Allow internal components to cool before service
• Control the spring during removal/installation—springs are under tension and can snap back
• Note the original spring orientation and attachment points to ensure proper reassembly

This generator assembly senses motor rotation and provides the control board with speed/position feedback so the washer can time cycles and spin properly. It replaces a worn or damaged sensor assembly to restore reliable cycle control. What it does:

• Detects motor rotation and sends position/speed signals to the washer control board
• Helps the machine maintain correct spin speeds and cycle timing
• Can address symptoms like no spin, erratic spinning, or motor-related error codes when the generator fails
• Works with the motor/mounting components to ensure accurate feedback for drive operations

• One generator assembly

• Disconnect power before servicing to avoid shock or injury
• Requires basic tools and access to the washer's motor area; handle connectors and sensor surfaces carefully
• Reuse or replace any mounting hardware only if specified by the manufacturer

The DC pump motor assembly powers the pump that moves water through your appliance. Replacing a worn motor helps restore proper water flow so cycles can complete and reduces issues like standing water and excessive noise.

• Drives the pump impeller to move water for draining or circulation, as designed by the appliance
• Supports proper cycle completion by clearing water from the tub or sump
• Common symptoms of a failing motor include standing water, incomplete draining/circulation, loud humming or grinding near the pump, or cycle errors
• May run intermittently, stall, or overheat as internal components wear

• Disconnect power and turn off the water supply before servicing
• Expect residual water; protect the area with towels or a shallow pan
• Note wiring connectors and hose routing; transfer any brackets, grommets, or seals from the original as needed
• Secure hose clamps and test for leaks while running a brief test cycle

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.

This self-tapping screw fastens panels, brackets, and internal components in compatible appliances. Replace a stripped, corroded, or missing screw to restore a secure fit and help prevent vibration, rattling, and misalignment.

• Forms/engages its own threads in sheet metal or plastic for a secure hold
• Secures covers, brackets, and assemblies to maintain alignment
• Helps reduce vibration and noise from loose components
• Replace if the head is stripped/broken, threads are worn, or the screw is missing

• Disconnect power and shut off water or gas, as applicable, before servicing
• Match to the original location and hardware; use identical length and thread where specified
• Start by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving hole is damaged, repair it before installing the new screw
