Parts for Whirlpool WED5010LW0: Top And Console Parts

This electronic control board manages the oven's user interface and operation, restoring responsive controls and proper cycle control for baking, broiling, timers, and displays. Replaces a failed console control to bring back normal oven function. What it does

• Interprets touchpad/selector inputs and sends commands to heat elements, igniters, and other oven components
• Controls oven temperature, bake/broil cycles, timers, and display readouts
• Resolves symptoms like unresponsive touchpad, blank or incorrect display, or ovens that fail to start cycles
• Works with associated relays/sensors; does not include user interface keypad or display lens

• One electronic control board

• Disconnect power to the appliance before starting any work to avoid shock or damage
• Handle the board by the edges and avoid static discharge; some soldered or plug-in connectors may be fragile
• Installation typically requires access to the control console—retain all screws and note connector locations for reassembly
• Test the appliance after installation; if errors persist, check related sensors, wiring, and connectors

This wire harness is a factory replacement electrical assembly that routes power and signals between components to restore proper appliance function. It helps re-establish reliable connections and resolve issues caused by damaged or frayed wiring. What it does:

• Replaces damaged or broken wiring that can cause intermittent operation or loss of power to components
• Carries electrical power and control signals between controls, motors, sensors, and other modules
• Restores secure, insulated connections to reduce arcing and short circuits
• Helps eliminate faults caused by loose, burnt, or corroded wires and terminals

• One complete wire harness assembly as shown

• Always disconnect power (unplug or shut off breaker) before starting any repair
• Handle connectors gently; match keyed plugs and fully seat each terminal to ensure good contact
• Route harness along original path and secure with existing clips/fasteners to avoid heat or pinch points

The Console Clip is an OEM part compatible with Whirlpool dryers. This clip secures the control console assembly to the top panel, ensuring it is firmly mounted during operation. Properly functioning clips are necessary to maintain the correct alignment of controls and prevent detachment.

Causes of a bad clip can include wear and fatigue from repeated opening and closing of the dryer door. Excessive force or impact could also bend or break the clip over time.

Symptoms of a bad clip include:

• Loose console assembly that is not securely fastened
• Misaligned or dangling controls that do not sit flush
• Dislodged console at risk of detaching from housing
• Missing clip leaving an open mounting point

This OEM Whirlpool replacement clip is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This 8-18 x 5/8-inch screw secures appliance panels, brackets, and covers. Replacing a missing or stripped fastener restores a tight fit and helps prevent vibration or loosening where this exact size is specified.

• Fastens sheet-metal or plastic components where a #8-18 x 5/8 screw is called for
• Helps maintain alignment and reduce rattling or vibration
• Replaces stripped, corroded, or missing screws of the same size
• Common symptoms: loose panels, gaps/poor fit, rattling noises, or visible missing hardware

• Disconnect power and shut off gas/water (as applicable) before service
• Match thread and length to the original; replace screws one at a time to keep parts aligned
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving threads are damaged, additional repair (clip, insert, or new nut) may be needed

This replacement screen filters debris within your appliance to help protect internal components and maintain proper performance. A clean, intact screen supports consistent flow and reduces the risk of clogs or premature wear.

• Traps debris to help prevent clogs in the designated flow path
• Helps protect downstream parts such as valves, pumps, or passages
• A torn, missing, or clogged screen can contribute to reduced performance, unusual noises, slow flow, or error codes
• Restores proper flow when replaced with a new, clean screen

• Disconnect power and, if applicable, shut off water or gas before servicing
• Access the screen per your model's service information and note its orientation
• Clean the mating area and remove any debris before installing the new screen
• If the original screen used an O-ring or seal, transfer it if reusable or replace as needed; seat fully and check for leaks or proper operation

This factory fastener is a #8-18 x 5/8-inch Type AB screw designed for appliance assembly. It secures panels and components to restore a tight, rattle-free fit and dependable alignment. What it does:

• Thread-forming Type AB design engages thin metal or plastic components
• Secures panels, brackets, trim, or covers to reduce looseness and vibration
• Replaces missing, stripped, or corroded fasteners
• Helps maintain alignment for proper operation and reduced noise

• One screw

• Disconnect power before servicing; shut off water supply if working near water lines
• Use the correct driver for the screw head; start by hand to avoid cross-threading
• Tighten until snug—do not overtighten to prevent stripping or cracking plastic
• Repair damaged holes or replace worn clips/inserts before installing the new screw

• Size: #8-18 x 5/8 in (length 0.625 in)
• Thread type: Type AB, thread-forming

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This replacement nut secures appliance parts and hardware to keep assemblies stable and prevent loose connections. It's a simple, direct replacement for worn or missing fastening hardware to restore proper fit and reduce vibration. What it does:

• Fastens mounting studs, brackets or panels to hold components in place
• Restores secure mechanical connections that can loosen over time
• Helps eliminate rattling, vibration and misaligned panels caused by missing or stripped hardware
• Provides a straightforward, durable replacement for corroded or damaged nuts

• Disconnect power to the appliance before beginning any repair
• Use the correct-size wrench or socket; ensure threads engage smoothly before tightening
• Tighten until snug—avoid overtightening that can strip threads or damage components
• Inspect mating threads and replace any damaged studs or hardware for a reliable repair

This replacement control knob restores a secure, easy-to-use grip for turning stove or oven controls so you can set temperatures and burners reliably. It replaces a worn, cracked, or missing knob to restore normal control operation. What it does:

• Provides a firm grip and clear pointer for adjusting oven or cooktop controls
• Replaces cracked, stripped, loose, or missing knobs that won't engage the control shaft
• Helps prevent accidental changes by fitting snugly on the valve or shaft
• Restores tactile feedback for accurate temperature or burner selection

• One control knob

• Disconnect power (or turn off gas supply) and ensure controls are cool before replacing
• Pull the old knob straight off the control shaft; align the new knob and push on until fully seated
• If knob is tight or stuck, gently wiggle while pulling; do not use excessive force or metal tools that could damage the shaft

This console control panel assembly restores the front-facing controls and display for your appliance, making it easy to select cycles and view settings. It replaces a cracked, faded, or non-responsive console to regain normal operation. What it does:

• Houses the touchpads, buttons and display used to select cycles and options
• Transmits user inputs to the appliance control so settings change as expected
• Replaces consoles with cracked, broken, or cosmetically damaged bezels
• Can resolve symptoms like unresponsive buttons, missing/blank display segments, or stuck controls

• Disconnect power before beginning any repair to avoid shock or injury
• Installation typically requires removing the console bezel and securing fasteners; keep small screws and clips organized
• Handle the display and trim carefully to avoid scratching or cracking the plastic
• If connectors are present, confirm they are fully seated; do not force mismatched plugs

The Clip is an OEM part for Whirlpool dryers. This part secures the control knob to the dryer’s control panel, ensuring it remains firmly attached and functions correctly. The clip helps provide stability and precise control over the dryer settings.

Causes of a bad clip can include regular wear and tear, accidental damage during use, or stress from frequent adjustments.

Symptoms of a bad clip include:

• Knob becoming loose or falling off
• Difficulty turning the knob to adjust settings
• Knob not staying securely in place
• Knob wobbling or feeling unstable

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This adjustable buzzer kit replaces a failed or noisy mini buzzer to restore audible alerts for cycles, timers and notifications. Compact design lets the appliance signal you reliably when cycles finish or need attention. What it does:

• Produces audible tones for cycle end, timers and other appliance notifications
• Replaces buzzers that are silent, intermittent, weak or emitting erratic beeps
• Helps you hear and identify completed cycles and timed alerts
• Small, mountable unit that fits behind the control panel and connects to the control board

• One adjustable buzzer kit

• Disconnect power before servicing to avoid shock risk
• Access may require removing the control panel; keep fasteners organized for reassembly
• Disconnect the buzzer wiring harness or connector before removing the old unit; connect the new buzzer the same way
• Test buzzer function with power restored before fully reassembling

The Switch Mounting Screw is an OEM part compatible with Whirlpool washing machines. This screw securely mounts the cycle selector switch within the control console assembly. Proper fastening ensures dependable operation of control functions.

Causes of a bad mounting screw can stem from stress cracks developing over multiple years of operation. Vibrations accumulate, slowly loosening connections housed in a wet environment.

Symptoms of a bad mounting screw include:

• Loose or rattling switch within the console face
• Difficulty selecting cycles as buttons wobble out of place
• Water intrusion hastening corrosion of electrical terminals
• Potential shock hazards if live connections are exposed

This Whirlpool replacement screw restores a tight mounting point. It is compatible with brands like Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Specs: 10-16 x 1/2 inch.

This mega encoder control is the electronic encoder assembly used on select residential dryers to monitor and communicate rotary/position signals to the main control, helping the dryer select and run the correct cycles. Replaces a worn or failed encoder to restore proper control signaling. What it does:

• Detects rotary/position input and sends encoder signals to the dryer control board
• Helps the control recognize selected cycles and timing inputs
• Commonly linked to symptoms such as unresponsive cycle selection, incorrect cycle behavior, or control errors
• Works as the interface for encoder-driven cycle selection on compatible dryer models

• Follow the dryer manufacturer's service manual for disassembly and wiring diagrams
• Disconnect power before servicing to avoid electric shock
• Handle the encoder and associated wiring carefully to avoid damage to connectors or flex circuit

This replacement screw secures appliance panels and components. Use this OEM fastener to swap out stripped, corroded, or missing hardware so assemblies stay tight, aligned, and quiet for reliable day-to-day operation.

• Provides secure attachment for panels, brackets, and internal assemblies
• Direct replacement for stripped, corroded, or lost screws
• Can help with symptoms like vibration, rattling, or loose/misaligned parts
• Supports proper fit to reduce gaps or unwanted movement

• Disconnect power; for gas or water appliances, shut off the supply before service
• Note hardware order and retain any spacers or clips from the original setup
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Repair or replace the mating part before installation
