Parts for Thermador PDR366ZS: 10 - Rear Oven Parts

This Broil Heating Element is an OEM part for Bosch Ranges. It is responsible for providing high heat for broiling functions and evenly distributing heat within the oven cavity. It ensures efficient broiling performance for cooking various dishes.

A common issue with a malfunctioning Broil Heating Element is wear and tear over time, leading to potential element damage or failure. Frequent usage, or heating irregularities can compromise its function.

Symptoms of a defective Broil Heating Element may include:

• Uneven broiling or cooking results
• Inadequate heating or failure to reach desired temperatures
• Visible damage or signs of wear on the heating element

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This OEM replacement part is a motor assembly for ovens. The motor assembly is the main motor that powers the oven fan which is responsible for maintaining and adjusting the temperature in an oven. If the oven is no longer heating properly, turning on, or maintaining temperature, then the motor assembly will need to be replaced.To replace this part, make sure that the oven is unplugged. After it has been powered off, proceed to pull the oven out and away from the wall. Once moved, uninstall the back panel of the oven by removing the panel's mounting screws. After detaching the back panel, locate the motor housing on the back of the oven. Unthread the screws that hold the housing in place. Once removed, locate the mounting brackets that hold the motor in place and remove the screws that attach to the motor. Pull the old motor out of its place and install the new motor. Reinstall the back panel and restore power to the appliance.This genuine replacement part is sold individually and is compatible with Bosch, Gaggenau, and Thermador brand ovens.

A cable harness that routes and connects power and signal wires to restore proper electrical continuity and control communication in your appliance. Replaces a worn or damaged harness to help eliminate intermittent power or control faults. What it does:

• Provides bundled wiring and connector interfaces between control boards, motors, sensors, and switches
• Restores reliable electrical connections when original wires or terminals are frayed, broken, or corroded
• Can resolve symptoms such as intermittent operation, loss of power to components, or control panel communication errors
• Matches OEM connector types and wire routing to maintain correct electrical function

• Disconnect all power (unplug appliance or switch off breaker) before starting service
• Note wire routing and connector positions during removal to ensure correct reinstallation
• Handle connectors by the housing; avoid pulling on individual wires

This terminal block housing secures and insulates the appliance's wiring connections, protecting wire terminals and helping ensure reliable electrical contact. Replace a cracked or melted housing to restore a safe wiring connection. What it does:

• Holds and protects the terminal block where power wires connect to the appliance
• Keeps wire terminals insulated and positioned to prevent shorting or contact with chassis
• Addresses symptoms like exposed or broken housing, visible melting or cracking, loose or intermittent power at the connection
• Helps prevent arcing and reduces risk of wire chafing at the connection point

• Disconnect power at the breaker or unplug the appliance before starting any work
• Access may require removing the back or lower access panel
• Inspect terminals and wiring; replace damaged terminals or wiring as needed before installing housing
• Secure housing and verify all wire connections are tight before restoring power

This electronic PC board is the appliance's main control, processing inputs and directing power to components so cycles run correctly. Replacing a failed board can restore normal operation when the unit is dead, won't start, or stops mid-cycle.

• Interprets user inputs and sensor feedback to execute programmed cycles
• Switches relays to power motors, valves, heaters, and other loads as required
• Manages timing, temperature, and safety logic for consistent performance
• Typical failure symptoms: no power/won't start, unresponsive or erratic controls, cycles ending prematurely, recurring error codes

• Disconnect power before servicing; verify power is off with a meter
• Use ESD protection; handle the board by the edges to avoid static damage
• Move connectors one at a time to identical positions on the new board to prevent miswiring
• Some models require service-mode setup or calibration after installation—follow your model's service documentation

A replacement high-temperature cut-out that helps protect ovens by interrupting power if internal temperatures rise above safe levels. Restores the appliance's over-temperature protection so heating elements can be safely shut off when needed. What it does:

• Monitors oven temperature and opens the circuit if temperatures exceed a safe threshold to prevent overheating.
• Stops power to heating elements when tripped, preventing further temperature rise.
• Common symptoms of a failing cut-out: oven won't heat, continuous heating or no control over temperature, or oven shuts off unexpectedly.
• Used as a safety device in the oven's temperature-control system.

• Disconnect power at the breaker and allow the appliance to cool completely before servicing.
• Replace with the exact OEM cut-out and secure all wiring connections.

This transformer supplies the low-voltage power needed for an oven's interior lights so bulbs operate reliably. It restores proper lighting and helps stop flicker or complete loss of oven lamp function. What it does:

• Converts the oven's supply to the low-voltage output required by interior lamp circuits.
• Restores steady lamp operation when lights fail to come on or flicker.
• Works with the oven's light switch and control circuitry to deliver consistent voltage.
• Helps prevent false diagnostics caused by intermittent lamp power.

• One oven light transformer.

• Disconnect all power to the appliance before starting any repair.
• Accessible behind the control panel or chassis; remove panels carefully to reach the transformer.
• Note wire locations and secure all connectors; use proper wire connectors and strain relief.

The temperature sensor is an electronic probe that monitors internal appliance temperature and reports it to the control so it can regulate operation. Replacing a failed sensor restores more accurate temperatures and can clear temperature-related error codes. What it does:

• Senses internal temperature via resistance changes and sends the signal to the electronic control
• Helps the control reach and maintain the set temperature during operation
• Common failure symptoms: too hot/cold, won't reach set temp, long/short cycles, temperature error codes
• Can cause preheat to stall or the unit to shut off early (model dependent)

• Includes: 1 temperature sensor

• Disconnect power at the breaker before servicing
• Location and access vary by model; typically mounts with screws or a clip and connects to a 2-wire harness
• Handle the connector and wiring carefully; route and secure away from hot or moving parts
• After installation, clear stored errors and run a test cycle to proper readings

This pressure regulator controls and stabilizes incoming water pressure to the appliance, helping maintain consistent operation and protect internal valves and seals. Fits systems that use a 3/4 inch inlet regulator. What it does:

• Reduces high incoming water pressure to a safe, steady level for the appliance
• Prevents pressure-related leaks, valve chatter, and premature wear on seals
• Helps maintain consistent water flow for reliable cycles and operation
• Commonly replaced when irregular pressure, humming valves, or water leaks occur

• One pressure regulator (3/4 in.)

• Turn off water supply and power to the appliance before starting; relieve system pressure first
• Inspect connection fittings and seals; use appropriate thread sealant if required by the OEM
• Tighten to manufacturer torque recommendations and check for leaks after restoring water

Restore reliable baking performance with this bake heating element. Mounted at the bottom of the oven, it provides the primary heat source in Bake mode so the cavity reaches and maintains the set temperature for consistent results. What it does:

• Heats the oven in Bake mode to reach and hold the set temperature
• Failure can cause no heat in bake, very slow preheating, or uneven/undercooked results
• Visible cracks, blisters, or a broken coil indicate the element should be replaced
• A shorted element may trip a household breaker or blow a fuse

• One bake heating element

• Disconnect power at the breaker and allow the oven to cool before servicing
• Remove oven racks; take out the element's mounting screws and gently pull the element forward to access wire terminals
• Transfer wires one at a time to the new element; do not allow wires to fall back into the insulation
• Reinstall the element and panels, restore power, and test bake operation
