Parts for Kitchenaid KP26M1XQ2CE5: Color Variation Parts

This upper machined housing supports and aligns the appliance's drive/transmission assembly for smooth operation and reduced vibration. It replaces a worn or damaged support that can cause noise or imbalance. What it does:

• Provides a machined mounting surface for the transmission/drive assembly
• Keeps drivetrain components aligned to reduce wobble and noisy operation
• Helps maintain proper interaction between the transmission and tub/drum
• Commonly replaced when wear or damage causes vibration, grinding, or unstable spinning

• One upper machined housing

• Disconnect power and water before starting any repair
• Access may require removing outer panels or the cabinet
• Inspect related bearings, seals, and fasteners and replace if worn
• If you're not comfortable with drivetrain work, consider service

This housing is the replacement cabinet housing that secures and protects internal components, restoring proper alignment and appearance. It helps maintain safe operation by covering wiring and support points. What it does:

• Protects internal components and wiring from debris and damage
• Restores proper fit and alignment of adjacent panels and controls
• Reduces noise and vibration caused by loose or damaged cabinet parts
• Common symptom: visible cracks, gaps, or wobbling of the appliance exterior
• Common symptom: rattling or rubbing noises coming from the cabinet area

• Disconnect power (and water, if applicable) before starting any repair
• Handle panels carefully — edges may be sharp; wear gloves and eye protection
• Require basic hand tools (screwdrivers, nut drivers) to remove panels and fasteners
• Follow manufacturer instructions for reassembly and torque of fasteners

This housing assembly replaces the damaged or worn outer casing that protects internal components and keeps the appliance structure secure. Restores proper fit and prevents debris from contacting internal parts. What it does:

• Replaces cracked, broken, or misshapen housing sections that cause gaps or misalignment
• Helps stop rattling or vibration caused by loose or compromised panels
• Protects internal wiring, motors and other components from dirt and accidental contact
• Restores correct mounting points for adjacent panels and hardware

• Disconnect power (and water if applicable) before servicing to avoid shock or injury
• Follow OEM service manual for panel removal and reassembly; some screws/clips may be hidden
• Use proper tools and keep track of fasteners and seals to ensure a secure fit
• Inspect and replace damaged mounting points or adjacent parts as needed for a lasting repair

This replacement housing restores the appliance's exterior support and helps protect internal components from damage while returning a finished appearance. Fits the corresponding Whirlpool assembly and replaces damaged or cracked housings. What it does:

• Provides structural support for internal components and mounting points
• Protects wiring, controls, and internal parts from dust and impact
• Restores a secure, finished exterior to eliminate gaps or loose panels
• Can stop rattling or movement caused by a cracked or broken housing

• One replacement housing

• Disconnect power (unplug or switch off breaker) before beginning work
• Remove adjacent trim or panels as needed to access mounting screws
• Handle carefully to avoid scratching the finish and watch for sharp edges
• Secure all fasteners; test appliance operation after reassembly

This porcelain enamel finish restores the factory color and smooth, glossy surface to compatible ranges and cooktops, improving appearance and protecting underlying metal from wear and staining. What it does

• Replaces worn, chipped, or faded enamel finish to make the appliance look like new
• Provides a durable, heat-resistant surface that resists stains and everyday wear
• Matches the OEM "Empire Red" color for a cohesive, factory-correct appearance
• Helps protect the underlying metal from corrosion and further cosmetic damage

• One porcelain enamel finish (Empire Red)

• Disconnect power and gas before starting any repair
• Removal of trim, screws, or panels may be required; follow the appliance's OEM service instructions
• Handle with care to avoid chipping the enamel during installation

This Onyx black finish panel restores the appliance's exterior appearance with a factory-style color-matched surface for a clean, uniform look. Ideal for replacing a worn or mismatched decorative panel. What it does:

• Provides a color-matched exterior surface to restore cosmetic appearance
• Covers scratches, chips, or discoloration on the appliance trim or door area
• Replaces a damaged or faded decorative panel without changing function
• Keeps visible surfaces consistent with the appliance's Onyx black finish

• High-level cosmetic replacement; basic hand tools may be required
• Follow OEM instructions for removal and reattachment to avoid damaging adjacent parts
• Handle with care to avoid scratching the finish during installation
• Disconnect power before servicing

A replacement trim band that restores the finished edge around the appliance door or front frame for a clean, factory appearance. Helps protect the cabinet edge and keeps the panel aligned for smooth operation. What it does:

• Covers and finishes the door or front-frame edge to restore original appearance
• Helps hold the panel trim in place and prevents gaps or rubbing at the edge
• Reduces the chance of snags on clothing or items near the door opening
• Useful when trim is cracked, bent, or cosmetically damaged

• Disconnect power to the appliance before beginning any work
• Remove the outer panel or door trim per the service manual to access the trim band
• Replace the band carefully to avoid damaging adjacent trim or painted surfaces
• Use appropriate hand tools and follow OEM instructions

This gearcase is the drive transmission that transfers motor power to the washer agitator and basket, restoring normal agitation and spin performance. It replaces a worn or damaged transmission assembly to help the washer move and clean properly. What it does:

• Transfers motor torque to the agitator and tub so the washer can agitate and spin
• Restores normal agitation or spinning when the transmission is worn or stripped
• Stops slipping, grinding, or inconsistent motion caused by damaged gears
• Works with the motor coupling and drive components to maintain correct drive alignment

• One gearcase (transmission) assembly

• Disconnect power and turn off water supply before starting any repair
• Access may require removing the cabinet, drive belt, and motor—follow OEM service instructions
• Inspect adjacent parts (motor coupling, seals, fasteners) and replace any worn components

This gearcase is the washer transmission that transfers the motor's power to the agitator and tub so your washer can agitate and drain properly. Replaces a worn or damaged transmission to restore normal wash motion. What it does:

• Transfers motor torque to the agitator and inner tub to produce wash and spin actions
• Houses gears and shafts that control direction and agitation patterns
• Commonly replaced when the washer won't agitate, makes grinding or rumbling noises, or the agitator spins freely
• Works with the washer's clutch and motor coupling to enable load movement

• Disconnect power and water supply before beginning any repair
• Installation requires disassembly of the washer cabinet and removal of the agitator, drive coupling, and motor
• Inspect related parts (agitator, drive coupling, seals) and replace if damaged

This lower gearcase is the replacement gearbox that transfers motor power to the appliance's drum/rotating assembly, restoring reliable drive movement and reducing grinding or slipping during operation. What it does:

• Transfers motor rotation to the appliance's drum or rotating assembly for normal operation
• Restores proper drive engagement to stop slipping or intermittent rotation
• Eliminates grinding, scraping, or unusual drive noises when worn
• Helps prevent further wear to belts and related drive components

• One lower gearcase (onyx black) as pictured

• Disconnect power before starting and follow for disassembly/reassembly
• Installation typically requires panel removal and basic hand tools; support the drum/assembly while replacing the gearcase
• Inspect and replace worn belts, idlers, or fasteners as needed to ensure long-term operation

This gearcase is the main transmission assembly that transfers motor torque to the washer's tub and agitator, restoring normal agitation and spin performance when the original gearcase fails. What it does

• Converts motor rotation into the gear reductions needed for agitation and spin cycles.
• Commonly replaced for symptoms like no agitation, slow or failed spin, grinding or clunking noises during cycles.
• Contains internal gears and bearings that can wear or break, causing irregular movement or loss of drive.
• Works with the washer's motor coupling and drive components to re-establish reliable drum motion.

• One gearcase (transmission) assembly.

• Disconnect power and water supply before beginning any repair.
• Support the washer cabinet and tub when removing the old gearcase to avoid damage or injury.
• Gearcase assemblies are heavy and contain grease—expect some lubricant exposure; clean hands and work surfaces after installation.
• Use model-specific service manual or exploded parts diagram for proper alignment and reassembly; replacement may require transfer of seals or mounting hardware.

Color: Copper Pearl

This planetary gear assembly drives the agitator/inner transmission components in compatible top-load washers, restoring smooth rotational motion and reliable agitation for normal wash cycles. What it does:

• Transfers motor torque through the transmission to the washer agitator for proper wash action
• Helps restore smooth, even rotation and reduces slipping or erratic agitation
• Commonly replaced when you hear grinding, clunking, or when the agitator fails to rotate normally
• Works with the washer's gearcase/transmission as part of the drive train

• Replacement requires disassembly of the washer transmission/agitator; refer to your model's service manual
• Disconnect power and water, and remove the washer cabinet or transmission cover before starting
• Inspect surrounding seals and fasteners while the unit is open; replace any worn components as needed

This is the planetary assembly for select stand mixers. It's the lower drive that holds the beater shaft and transfers power from the gearcase to rotate the beater for efficient mixing.

• Transfers torque from the mixer's gear train to the beater shaft
• Supports smooth, consistent beater rotation
• Worn planetary can cause wobbling beater, grinding/rumbling noises, poor mixing, or intermittent beater motion
• Needed if the beater shaft has excessive play or the gear teeth are damaged

• Unplug mixer before servicing; remove bowl and attachment
• Head must be opened to access and remove the retaining pin/fasteners
• Support the lower assembly when separating it from the gearcase to avoid damage
• Re-grease gears if specified by the service manual and proper beater-to-bowl clearance after reassembly

The Planetary is an OEM part for Whirlpool stand mixers. This part holds the beater and ensures it rotates around the bowl to mix ingredients thoroughly. The planetary mechanism allows for consistent and even mixing by moving the beater in a planetary motion, which covers the entire bowl.

Causes of a bad planetary can include regular wear and tear, heavy use, or mechanical failure within the gears.

Symptoms of a bad planetary include:

• Beater not rotating properly
• Unusual noises during operation
• The mixer head wobbling or shaking
• Inconsistent mixing results

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

The Planetary Assembly is an OEM replacement part for Kitchenaid stand mixers. It is the central component that transmits rotational power from the motor to the mixing attachment through an intricate system of gears.

Causes of a bad planetary assembly can include worn gears that no longer mesh properly, broken or missing gear teeth from overloading, or a failed bearing.

Symptoms of a bad planetary assembly include:

• Slipping or jumping of gears during mixing
• Grinding or scraping noises
• Inability to mix thoroughly on higher speeds
• Premature failure of the motor

This OEM replacement is also compatible with Maytag, Whirlpool, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This Empire red touch-up paint restores the original appliance finish to cover chips, scratches, and small blemishes for a clean, uniform look. Ideal for maintaining the appliance's appearance between larger repairs or panel replacements. What it does:

• Matches the Empire Red appliance color to conceal chips and surface scratches
• Prevents small bare spots from showing and improves overall cosmetic appearance
• Helps maintain consistent color on exterior panels and trim
• Useful for spot repairs after minor impacts or wear

• Clean and dry the surface thoroughly; remove grease and loose paint before applying
• Apply in thin coats, allowing recommended dry time between coats for best results
• Test on an inconspicuous area first to confirm color match
• Follow all product label warnings; use in a well-ventilated area and keep away from heat and open flame
