Parts for Whirlpool WCC31430AB02: Cooktop Parts

Color: Black

Color: White

This replacement light lens covers the appliance's bulb, protecting it from contact, moisture, and splashes while diffusing illumination. Replacing a cracked or missing lens restores safe, even lighting and keeps the bulb properly shielded. What it does:

• Shields the bulb from contact, moisture, and debris
• Diffuses light for more even illumination with reduced glare
• Helps protect the socket area from contamination
• Typical symptoms: cracked, warped, or missing lens; discoloration; exposed bulb; harsh or uneven lighting

• Includes: 1 light lens

• Disconnect power to the appliance before servicing; allow the lamp/area to cool completely
• Wear gloves and eye protection when handling an old or broken lens
• Remove retaining screws, tabs, or clips and note lens orientation for reassembly
• Reuse existing hardware if required; do not overtighten; restore power and test light operation

The Whirlpool Infinite Switch is an OEM part for Whirlpool ranges. Whirlpool electric ranges. This switch controls the multiple heat settings of the small element, allowing the user to select their desired cooking temperature. It is an important electrical component that regulates burner heating cycles.

Symptoms of a bad infinite switch include:

• The element not heating up adequately or failing to maintain temperature
• Inability to select or change heat settings on the
• Burner operates intermittently or fails to heat properly

Causes of a bad infinite switch can include failure over many heating cycles. The electrical contacts within the switch may become corroded or deteriorate from repeated exposure to cooktop temperatures and cooking residue.

It is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore electric range models.

The Whirlpool Infinite Switch is an OEM part for Whirlpool ranges. Whirlpool electric ranges. This switch controls the multiple heat settings of the large element, allowing the user to select their desired cooking temperature. It is an important electrical component that regulates burner heating cycles.

Symptoms of a bad infinite switch include:

• The element not heating up adequately or failing to maintain temperature
• Inability to select or change heat settings on the
• Burner operates intermittently or fails to heat properly

Causes of a bad infinite switch can include failure over many heating cycles. The electrical contacts within the switch may become corroded or deteriorate from repeated exposure to cooktop temperatures and cooking residue.

It is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore electric range models.

Replacement indicator light for control panels that restores visible status and cycle feedback. Ideal when the control-panel light is dim, cracked, or not illuminating—helps active functions and cycle progress at a glance. What it does:

• Illuminates to indicate active functions and cycle/status information on the control panel.
• Replaces a cracked, burnt-out, dim, or non-functioning indicator light.
• Common symptoms it can fix: a dark, flickering, or intermittently working panel indicator.

• Disconnect power (unplug or shut off the circuit breaker) before servicing the appliance.
• Access may require removing the control panel or lens; follow the owner's manual or service guide for panel removal.
• Handle the light and lens carefully to avoid damage; avoid touching bulb surfaces with bare hands.

Size: 8-32 x 1/4 inch.

The Stove Top Drip Pan is an OEM replacement part for Whirlpool gas and electric ranges. It is located underneath the stove burners and grates to catch and contain grease drippings and spills. Over time, grease and cooking residue buildup can cause drip pans to crack, warp or corrode.

Symptoms of a bad stove top drip pan include:

• Grease spillovers outside of the drip pan area
• Flames or heating elements obstructed by built-up debris
• Warping or cracking of the pan surface
• Difficulty removing or cleaning the drip pan

Causes can be normal wear from heat and long-term grease exposure. Accidental damage during cleaning is also possible.

 This OEM part is also compatible with Maytag, Jenn-Air, Amana and some Kenmore models.

The Stove Top Drip Pan is an OEM replacement part for Whirlpool ranges. It is the shallow metal pan located below the stove burner elements that collects grease and food particles. The drip pan helps direct spills and drips away from the burner area to the bottom drawer for easy cleanup.

Symptoms of a bad drip pan include:

• Grease or food spilling below the burners outside of the pan
• Burner elements showing signs of corrosion or damage from drips
• The drip pan no longer fitting properly or securely in place

Causes can be warping or damage of the drip pan over time due to exposure to heat. Dents and structural changes compromise its ability to direct drips properly.

This OEM replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

If you require a compatible 6-inch drip bowl, suggest considering our WPW10196406 model for a perfect fit. For a black option include the 6-inch W10290353RW and 8-inch WPW10290350 models.

This surface heating element replaces a damaged top burner so your range can heat cookware properly. It reconnects the cooktop's electric heating circuit to restore normal cooking performance and reliable heat. What it does:

• Heats cookware on the cooktop's top burner for boiling, frying and simmering
• Replaces cracked, burned-through or non-heating surface element units
• Commonly used when a burner won't heat, heats intermittently, or shows visible damage
• Matches the OEM element design and mounts at the cooktop surface using existing terminals

• Disconnect power to the range at the breaker before inspecting or replacing the element
• Allow the cooktop and element to cool fully; handle terminals by the insulated ends
• Remove and note connector positions before disconnecting wires to ensure correct reassembly

The Surface Element is an OEM component specifically designed for Whirlpool ranges and cooktops. It provides the heating source for cookware on the stove surface.

Causes of a bad element include deterioration of insulation material over time, carbonization or damage from pans slammed onto the element, or contact with moisture.

Symptoms of a bad element include:

• Inability to heat cookware sufficiently
• Uneven or incomplete heating of pans placed above
• Burn marks or discoloration visible on the element
• Crackling or popping noises heard from below pans

This part is also compatible with some Kenmore, Frigidaire, and select GE range models. Proper cooking performance and safety are maintained with an OEM surface element replacement when needed.

Size: 10-24X5/16-NI

Color: White

This Control Knob is an OEM replacement part for Whirlpool electric cooktops. It fits over the infinite switch to control the heat levels of the surface elements. This knob allows for the adjustment of temperature settings, enabling users to easily select the appropriate heat levels for cooking.

Color: Black

Over time, the control knob can become damaged or worn out due to regular use. Issues like a loose or cracked knob, difficulty in turning it, or the knob not staying securely in place could indicate the need for replacement.

Symptoms of a faulty Cooktop Control Knob include:

• Difficulty turning the knob or selecting heat levels
• The knob feels loose or wobbly
• The knob is cracked or visibly damaged

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Replacement screw used to secure components and panels in household appliances, restoring proper fit and effectively reducing movement or rattling from loose or missing fasteners. What it does:

• Secures panels, trim and internal components to keep parts aligned and stable.
• Helps stop rattling, vibration or noise caused by loose or missing fasteners.
• Restores proper mounting for brackets, covers and control housings.
• Useful wherever a worn or stripped screw is causing play or loose parts.

• Disconnect power and unplug the appliance before doing any work.
• Use the correct driver and size to avoid stripping the head or threads.
• Tighten snugly but avoid overtightening—replace with the exact OEM screw when specified.

Size: 10-24X5/16-NI
