Parts for Whirlpool 7MWTW1503AW1: 04 - Gearcase, Motor And Pump Parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

The Drain Pump is an OEM part for Whirlpool washing machines. This component is essential for removing water from the washer during the drain cycle. It ensures that water is efficiently pumped out of the washing machine, preventing water from remaining in the tub after a wash cycle, which is crucial for the appliance's proper operation and the cleanliness of your laundry.

You should replace the drain pump if it becomes faulty or stops working. Common causes of a bad drain pump include blockages from debris or lint, wear and tear over time, or electrical malfunctions. These issues can prevent the pump from effectively draining water.

Symptoms of a bad drain pump include:

• Water not draining from the washing machine
• Unusual noises during the drain cycle, such as humming or grinding
• The washer stopping mid-cycle with water still in the tub
• Error codes related to draining issues on the washer's display

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This factory fastener secures appliance panels and components for a tight, rattle-free fit. Replace a missing, stripped, or corroded screw to keep assemblies aligned and performing as intended.

• Fastens panels, brackets, or assemblies in place
• Helps reduce vibration and rattling caused by loose hardware
• Maintains proper alignment of parts to prevent premature wear
• Common signs you need it: missing screw, loose panel, vibration/buzzing noises, or hardware that won't tighten

• Disconnect power; for gas or water-connected appliances, shut off supply lines before service
• Match the screw to the original; verify size, length, and thread before installation
• Start threads by hand to avoid cross-threading; use the correct driver bit
• Snug only—do not overtighten, especially into plastic or thin sheet metal

The Hose Clamp is an OEM part for Whirlpool washing machines. This clamp secures the hose in place, ensuring a tight connection and preventing leaks during operation. It is essential for maintaining the integrity of the washing machine's water system, securing hoses that carry water to and from the washer.

Common causes of a bad hose clamp include rust, physical damage, or loosening from repeated tightening and loosening.

Symptoms of a bad hose clamp include:

• Water leaks around the hose connection points
• The hose slipping off the fitting
• Visible rust or wear on the clamp
• Difficulty in tightening the clamp to secure the hose

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and some Kenmore models.

The Washer Gear Case is an OEM part for Whirlpool washing machines. It is a critical component that houses the gears responsible for the rotation and agitation of the washer drum. This gear case ensures that the washer performs its washing cycles effectively by providing the necessary mechanical movements.

Causes of a bad gear case can include wear and tear from prolonged use, lubrication breakdown leading to increased friction, or damage from overloading the washer. Additionally, exposure to water leaks can lead to corrosion and deterioration of the internal components.

Symptoms of a bad gear case include:

• Unusual grinding or clunking noises during the wash cycle
• The drum not spinning or agitating properly
• Leaks of oil or grease underneath the washer
• The washer failing to complete its cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This replacement 7-2-1 screw secures components in compatible Whirlpool appliances, providing a dependable fastener for panels and assemblies. Use it to restore proper fitment and reduce rattling or loose parts. What it does

• Fastens trim, panels, brackets, or internal assemblies to keep parts secure
• Helps stop vibration-related noise from loose components
• Restores correct mounting where the original screw is missing or damaged
• Matches the form and fit of the OEM fastener for intended attachment points

• One replacement 7-2-1 screw

• Use the correct driver to avoid stripping the screw head
• Hand-start threads before tightening to prevent cross-threading
• Tighten until snug—do not over-tighten to avoid damaging plastic or sheet-metal parts
• Disconnect power to the appliance before accessing internal areas

This 1/4 HP motor assembly replaces a worn drive motor to restore proper drive power and rotation. It's a direct-fit mechanical motor intended to bring moving components back to OEM performance and reliable operation. What it does

• Provides drive power for the appliance's rotating components to restore normal operation.
• Replaces a failed or noisy motor that causes little or no rotation, intermittent operation, or a humming/stalling condition.
• Helps eliminate abnormal motor noise, vibration, or overheating when the motor is the root cause.
• Restores consistent mechanical speed and torque for components that rely on the motor to function.

• One 1/4 HP motor assembly

• Disconnect power before servicing; follow all safety precautions.
• Verify mounting orientation, shaft alignment, and proper belt/drive configuration during reassembly.
• Inspect and replace worn belts, pulleys, or mounting hardware as needed to prevent repeat failures.

The Drive Clutch Kit is an OEM replacement part for Whirlpool washing machines. As an integral transmission component, it includes the clutch that engages the drive motor to rotate the central agitator or impeller.

Causes of a bad clutch kit include worn parts that have aged from repeated use. Signs include slipping, grinding, or clicking noises from the transmission area.

Symptoms of a faulty clutch kit are:

• The washer tub failing to turn or agitate clothes during wash cycles
• Delayed starts or intermittent rotation
• Vibration or shaking sensed from the frontloader or toploader

This OEM replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Drive Clutch Kit is an OEM replacement part for Whirlpool washing machines. As an integral transmission component, it includes the clutch that engages the drive motor to rotate the central agitator or impeller.

Causes of a bad clutch kit include worn parts that have aged from repeated use. Signs include slipping, grinding, or clicking noises from the transmission area.

Symptoms of a faulty clutch kit are:

• The washer tub failing to turn or agitate clothes during wash cycles
• Delayed starts or intermittent rotation
• Vibration or shaking sensed from the frontloader or toploader

This OEM replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Drive Clutch Kit is an OEM replacement part for Whirlpool washing machines. As an integral transmission component, it includes the clutch that engages the drive motor to rotate the central agitator or impeller.

Causes of a bad clutch kit include worn parts that have aged from repeated use. Signs include slipping, grinding, or clicking noises from the transmission area.

Symptoms of a faulty clutch kit are:

• The washer tub failing to turn or agitate clothes during wash cycles
• Delayed starts or intermittent rotation
• Vibration or shaking sensed from the frontloader or toploader

This OEM replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Drive Clutch Kit is an OEM replacement part for Whirlpool washing machines. As an integral transmission component, it includes the clutch that engages the drive motor to rotate the central agitator or impeller.

Causes of a bad clutch kit include worn parts that have aged from repeated use. Signs include slipping, grinding, or clicking noises from the transmission area.

Symptoms of a faulty clutch kit are:

• The washer tub failing to turn or agitate clothes during wash cycles
• Delayed starts or intermittent rotation
• Vibration or shaking sensed from the frontloader or toploader

This OEM replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Drive Clutch Kit is an OEM replacement part for Whirlpool washing machines. As an integral transmission component, it includes the clutch that engages the drive motor to rotate the central agitator or impeller.

Causes of a bad clutch kit include worn parts that have aged from repeated use. Signs include slipping, grinding, or clicking noises from the transmission area.

Symptoms of a faulty clutch kit are:

• The washer tub failing to turn or agitate clothes during wash cycles
• Delayed starts or intermittent rotation
• Vibration or shaking sensed from the frontloader or toploader

This OEM replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This replacement nut is a small hardware fastener used to secure components inside your appliance. It helps keep parts tight and properly aligned so assemblies don't loosen from vibration or normal operation.

• Threads onto a mating bolt, stud, or shaft to clamp parts together
• Maintains alignment and reduces movement and rattling
• Replaces a stripped, missing, or damaged nut to restore a secure fit
• Common signs of failure: loose panels or components, unusual vibration/noise, hardware missing

• Disconnect power; shut off gas and/or water if applicable before servicing
• Note the original hardware stack-up (washers/spacers) and orientation for reassembly
• Start by hand to avoid cross-threading; tighten to manufacturer guidance—do not overtighten
• Replace any damaged washers or locking devices

The washer drive belt transfers motor power to the washer’s drive system so the basket spins and agitates. Replacing a stretched or broken belt helps stop squealing and slipping so cycles finish at proper spin speed.

What it does

• Links the drive motor to the washer’s drive/pulley system
• Restores spin and agitation when the belt is worn, glazed, or broken
• Can reduce squeal or burning-rubber smells from belt slip
• Helps prevent intermittent or no-spin conditions

What’s included
One drive belt.

Install notes

• Unplug power; turn off water
• Tip the washer back; remove the bottom shield/cover if present
• Route the belt over the motor and drive pulleys; rotate by hand to seat fully
• Inspect pulleys/drive parts for wear; run a spin or calibration test after install

This OEM Whirlpool belt is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore washer models.

The Shift Actuator is an OEM replacement part for Whirlpool washing machines. It is an electronic component located inside the transmission that controls the shifting between wash cycles. The shift actuator receives signals from the washer control board to change modes, initiating proper movements to advance the cycle.

Symptoms of a bad shift actuator include:

• The washer fails to advance through cycles properly
• Gets stuck in one phase of the wash cycle
• Makes abnormal noises during operation
• Does not agitate or spin as expected

Over time, environmental factors and normal wear and tear can cause the shift actuator to malfunction.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

NOTE: This new version of the part features a redesigned black plastic housing with an adapter wire harness. It replaces the older version that came in red plastic. The new part is guaranteed to fit and function like the original.

This capacitor stores and releases electrical energy to give the appliance's circuit the boost and stability it needs to start and run properly. Replacing a weak or shorted capacitor can restore reliable operation and reduce strain on related components. What it does

• Provides an energy boost and stabilizes voltage in the designated start/run or power circuit
• Helps motors or power sections energize smoothly and maintain performance
• A failing capacitor may cause humming/buzzing, failure to start or heat, intermittent operation, or tripped fuse/breaker
• May show swelling or signs of overheating around the case or terminals

• 1 capacitor

• Disconnect power before service; capacitors can hold a charge—use a proper discharge procedure before handling
• Note/photograph wire locations; move leads to matching terminals and ensure tight connections
• Mount securely in the original position; re-use brackets/insulators as applicable and keep wiring clear of sharp edges or heat
• After replacement, check the related motor or circuit components if symptoms persist

This factory screw secures appliance panels and components, keeping them properly aligned and quiet during operation. Replace a stripped, corroded, or missing fastener to restore a snug fit and dependable performance in the original mounting location. What it does:

• Fastens brackets, panels, trim, or internal hardware to the cabinet/frame as specified by the manufacturer
• Helps maintain proper alignment and reduce rattling or vibration when a screw is worn or missing
• Direct replacement for damaged, stripped, or rusted hardware
• Used in various locations per the service diagram; match to the original position

• 1 screw

• Disconnect power (and shut off water or gas, if applicable) before servicing.
• Compare length and thread style to the original; install in the same location.
• Start threads by hand to avoid cross-threading; tighten until snug—do not overtighten.
• Reinstall any brackets or panels in the correct order.

This pulley cover encloses the drive belt and motor pulley at the base of the appliance. It protects moving parts from debris and contact, helping reduce noise and wear when the original cover is cracked, warped, or missing.

• Covers the drive belt and motor pulley to keep out dust and debris
• Helps prevent foreign objects from contacting moving parts
• Restores proper clearance to reduce rubbing or scraping noises
• Common signs it's needed: cracked/missing cover, rattling from the base, visible rub marks on the cover or belt

• Disconnect power and, if applicable, shut off water supply before servicing
• Access the underside per your service manual; support the unit securely if tilting
• Reuse existing mounting screws; do not overtighten to avoid damaging the plastic
• Rotate the belt/pulley by hand after installation to confirm free movement and no contact

Size: 16 fl. oz.

Catches lint, threads, and strings.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

Color: White. Size: 1 qt. can. Acrylic appliance paint.

These replacement 6" FXF vacuum bags capture dust and debris to restore pickup performance and keep the appliance's airflow and motor compartment cleaner. Designed as a direct-fit consumable for compatible bagged upright and canister vacuums. What it does:

• Collects dirt, dust and debris so particles stay contained for easier disposal
• Helps maintain suction by keeping the vacuum's intake and motor chamber clearer
• Reduces dust and allergen re-distribution compared with a torn or overloaded bag
• Replaces worn or full bags that cause reduced capacity, visible dust escaping, or increased odor

• Always unplug the vacuum before removing or installing bags
• Remove the full bag carefully to avoid spilling debris; seal and dispose per local regulations
• Verify correct orientation and secure fit before operating to avoid leaks
• Replace bags regularly; inspect the inlet collar and seals for wear when servicing

This siphon break kit prevents wastewater from siphoning back into the dishwasher, helping keep the tub and dishes clean and reducing drainback issues. Fits the dishwasher drain assembly to restore proper draining function. What it does:

• Stops backflow by breaking the siphon effect in the drain line
• Works with the dishwasher drain hose and pump to maintain one-way drainage
• Helps address symptoms like water remaining in the tub, partial drains, or water backing into the tub
• Supports proper drainage to reduce odors caused by standing water

• One siphon break kit

• Disconnect power to the appliance and turn off the water supply before starting
• Inspect the drain hose routing and secure the siphon break at the recommended height per the dishwasher's service instructions
• Use basic hand tools; hose clamps or fasteners may be required

Kit contains two 10 feet inlet hoses.

This drain hose coupling connects two sections of the washer drain hose to restore a watertight path for wastewater, helping prevent leaks and restore proper draining. What it does:

• Joins two drain hose sections or connects hose to a mating outlet for secure water flow
• Seals the hose connection to reduce leaks at the joint
• Restores proper draining when a damaged or missing coupling causes slow drain or leakage
• Designed to fit the OEM hose profile for a snug, stable connection

• One drain hose coupling as shown

• Turn off power and water supply before starting any repair
• Inspect hose ends for damage; trim to clean cut if required for proper fit
• Push hose ends fully onto the coupling and secure with manufacturer-recommended clamps

5 foot. Package of 2.

Color: Gray. Size: 13 oz. can. Used for coating the dryer drum interior. Acrylic appliance paint.

Replace aging or leaking washer supply lines with this fill hose kit. It provides two 5-foot hoses to connect your home's hot and cold water valves to the washer, helping maintain a secure connection and consistent filling.

• Connects hot and cold water faucets to the washer's inlet valves
• Replace if hoses are leaking, cracked, bulging, or kinked
• Can help address slow filling caused by restricted or kinked hoses
• Useful when installing or relocating a washer

• Unplug the washer and shut off both water supply valves before starting
• Place a towel or pan to catch residual water; disconnect old hoses from faucet and washer
• Match hot to hot and cold to cold; hand-start threads to avoid cross-threading, then tighten firmly without overtightening
• Restore water and power; run a fill test and check all connections for leaks

Size: .20 Fl. Oz. (6 ml)

This factory washer is used in appliance assemblies to distribute load under a fastener and maintain a secure, accurate fit. Replace a missing or damaged washer to restore proper stack-up and reduce vibration, noise, or loosening.

• Distributes load and provides proper spacing in the fastener assembly
• Helps keep bolts, screws, or nuts tight to minimize vibration and rattling
• Direct replacement when the original washer is worn, bent, cracked, or missing
• Typical signs include loose panels/brackets, recurring looseness after tightening, or new vibration after service

• Unplug the appliance; shut off water supply if working near hoses or valves
• Note the original hardware stack-up and reassemble in the same order
• Inspect mating surfaces and companion hardware; replace any damaged parts
• Tighten fasteners snugly per service guidance; avoid overtightening

Size: 29 1/4 inches x 31 1/4 inches. This universal washer drip tray is large enough for duet washers and sits under the washer to protect your floors from scuffs, spill, etc. Includes a PVC drain fitting.

This set of washer fill hoses connects your home's hot and cold water supply to the washer's inlet valves. Replacing aging hoses helps prevent leaks and ensures the washer fills properly for every cycle.

• Supplies hot and cold water from household faucets to the washer's inlet valves
• Helps address leaks, bulges, or cracks in old hoses
• Can resolve drips at fittings and water on the floor
• Improve slow or no-fill issues caused by kinks or internal blockages

• Unplug the washer and turn off both water supplies before starting
• Place a towel or pan to catch residual water; disconnect old hoses from faucets and inlet valves
• Attach new hoses to the correct hot/cold connections; tighten connections securely without overtightening
• Open valves, check for leaks at both ends, and re-tighten if needed

Contains two, six foot long braided hoses with 90 degree ends.

This drain hose extension kit increases the reach of your appliance's drain line so it can connect to a farther standpipe or sink, supporting proper drainage and reducing stress on fittings that can lead to leaks. What it does:

• Extends the existing drain hose to accommodate installations where the drain connection is farther away
• Helps maintain a secure, leak-resistant connection when routed correctly
• Useful when relocating the appliance, changing cabinetry, or updating plumbing
• Common signs you may need it: hose won't reach, kinks when stretched, or occasional water near the drain line

• One drain hose extension kit

• Disconnect power and shut off the water supply; have a towel or pan ready for residual water
• Join the extension to the existing drain hose with the proper coupling/clamps; tighten securely and avoid kinks or sharp bends
• Route and support the drain line per your model's installation guide and observe any maximum total hose length
• Run a short test cycle and check all joints for leaks

The Washer Fill Hoses are OEM parts for various washing machines, specifically designed to transport hot and cold water from the home's supply lines to the washer. These hoses are essential for the proper functioning of the washing machine, ensuring a steady and reliable flow of water during the wash and rinse cycles. Coming in packs of 2, each hose measures 5 ft.

Causes of bad washer fill hoses can include wear and tear over time, exposure to high water pressure, or damage from kinks and bends. Additionally, hoses can deteriorate due to exposure to harsh water conditions or chemical buildup.

Symptoms of bad washer fill hoses include:

• Leaks or puddles around the washing machine
• Reduced water flow into the washer
• Visible cracks or bulges in the hoses
• The washer taking longer than usual to fill with water

These washer fill hoses are compatible with a variety of washing machine brands and models, ensuring a secure and efficient water supply.

The Appliance Touchup Paint is an OEM product for Whirlpool appliances. This touchup paint is used to cover scratches, chips, and minor blemishes on the surface of various appliances, helping to maintain their appearance and protect them from rust and other damage. It is specifically formulated to match the original color and finish of Whirlpool appliances, ensuring a seamless repair.

Causes of needing touchup paint include everyday wear and tear, accidental impacts that cause chipping or scratching, and exposure to harsh cleaning chemicals that can damage the finish. Regular use of touchup paint can help keep appliances looking new and extend their lifespan.

Symptoms indicating the need for Appliance Touchup Paint include:

• Visible scratches or chips on the appliance surface
• Areas of exposed metal prone to rust
• Blemishes that affect the overall aesthetic of the appliance

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Color: White. Size: 13 oz can. Acrylic appliance aerosol can spray paint.

The Appliance Spray Paint is an OEM part for Whirlpool appliances, designed to provide a quick and effective way to touch up or completely refinish the exterior of various appliances. This specialty spray paint is formulated to adhere to metal surfaces, offering a durable and resistant finish that can withstand the routine wear and tear of kitchen environments, including heat, moisture, and everyday use.

The primary reason for using such a specialized paint is to maintain or restore the aesthetic appeal of your appliances while protecting them from further damage.

Symptoms needing for Appliance Spray Paint include:

• Scratches, chips, or rust spots on the appliance's exterior that can lead to further damage or corrosion if left untreated
• A desire to refresh or update the appearance of the appliance without the need for complete replacement
• Discoloration or fading of the original finish due to age, exposure to sunlight, or cleaning agents

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

The Inlet Hose Screen and Gasket is an OEM part for Whirlpool washing machines. This component is designed to filter debris from the water entering the machine and ensure a tight seal between the hose and the water inlet valve. By preventing debris from entering the washing machine, it helps to maintain the appliance's performance and longevity.

Causes of a bad inlet hose screen and gasket can include clogging from mineral deposits or debris, wear and tear over time, or damage due to improper installation or removal. A compromised screen or gasket can lead to reduced water flow and potential leaks.

Symptoms of a bad inlet hose screen and gasket include:

• Reduced water flow into the washing machine
• Visible debris or buildup on the screen
• Water leaks at the hose connection
• The washing machine not filling properly

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.
