Parts for Whirlpool WET3300SQ2: 01 - Washer / Dryer Control Panel Parts

This Dryer Timer is the electromechanical control that sequences your dryer through timed and automatic cycles. Replacing a failing timer restores proper cycle advancement so the dryer starts, runs for the selected time, and shuts off as expected.

• Controls cycle selection and total run time in timed and auto-dry modes
• Advances the timer dial and switches internal contacts for motor and heat circuits
• Common symptoms of failure: timer not advancing, dryer runs continuously or won't shut off, stops mid-cycle, or only certain cycles work

• Disconnect power; turn off gas supply for gas models
• Access the control panel; remove the knob and rear cover to reach the timer
• Transfer wires one at a time from the old timer to the new to maintain correct connections
• Secure the timer, reinstall the dial/knob, restore power, and test all cycle settings

This timer skirt assembly replaces a cracked, worn or loose dial skirt so the timer knob fits securely and operates smoothly. It restores proper knob alignment and protects the timer control opening. What it does:

• Replaces a broken or cracked dial skirt that lets the knob wobble or sit unevenly
• Helps the timer knob engage the control shaft correctly for reliable selection
• Covers and protects the timer mechanism from dirt and debris around the control
• Reduces knob play and improves the appearance of the control panel

• Disconnect power to the appliance before servicing to avoid shock or injury
• Typically requires removing the control knob and/or control panel; have basic hand tools ready
• Handle plastic parts gently to avoid cracking; align skirt before securing components

The Timer Knob is an OEM part for Whirlpool washers. This knob allows users to set and adjust the washing cycle by turning the timer to the desired position.

Causes of a bad timer knob can include regular wear and tear, accidental impacts, or over-tightening.

Symptoms of a bad timer knob include:

• Knob not turning smoothly or becoming stuck
• Cracks or breaks in the knob
• The knob slipping or not staying securely on the timer shaft
• Difficulty setting or changing the washing cycle

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Color: white. Measures about 2 inches in diameter.

This timer knob assembly attaches to the timer shaft and lets you accurately select cycle settings. Replace a cracked, missing, or slipping knob to restore smooth, reliable control of your appliance's timer.

• Interfaces with the timer's keyed shaft to select cycle and time settings
• Provides a solid grip to turn the timer without slipping
• Typical symptoms: knob cracked, falls off, spins freely, or won't reliably turn the timer
• Helps restore proper user control without affecting internal timer function

• Disconnect power before servicing
• Pull the old knob straight off the timer shaft; if your model uses a retaining clip or dial skirt, remove carefully for reuse
• Align the flat/keyed opening with the shaft and press on by hand until fully seated
• Rotate through settings to engage

This rotary temperature selector switch mounts in the console and lets you choose the temperature setting for a cycle. Replacing a worn switch restores accurate response to the control knob so the appliance follows the temperature you select.

• Converts the knob position into the correct electrical output for the chosen temperature level
• Helps ensure the appliance responds to the temperature setting selected on the control panel
• Common symptoms: only one temperature works, temperature won't change with the knob, selector feels loose or won't "click," intermittent temperature selection
• Typical causes include worn internal contacts or a damaged switch shaft

• Disconnect power before servicing
• Access the control console; remove the knob and retainers to free the switch
• Photograph or label wire positions, then transfer connectors to the new switch one at a time
• Secure the switch, reinstall the knob/panel, restore power, and test temperature selection

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The Start Switch is an OEM part for Whirlpool dryers. This switch is essential for initiating the drying cycle, allowing the user to start the dryer by pressing the button. It ensures the dryer begins operation and runs through the selected cycle properly.

Causes of a bad start switch can include electrical issues such as short circuits, mechanical wear from frequent use, or damage due to moisture or impact.

Symptoms of a bad start switch include:

• The dryer not starting when the button is pressed
• Intermittent operation or the need to press the button multiple times to start the dryer
• No response or sound when the start button is engaged
• The start button feeling loose or not clicking properly

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This control knob is the direct-replacement selector used to turn and set cycles or functions on compatible Whirlpool controls, restoring reliable user operation and tactile feedback. What it does

• Replaces a worn, cracked, or loose selector knob so the control can be turned and set easily
• Provides a secure grip and positive detent for selecting cycles or settings
• Prevents slipping or unintended changes to cycle selection
• Restores the original look and user interface of the control panel

• One knob assembly

• Disconnect power to the appliance before beginning any work
• Pull the old knob straight off the shaft; align splines on the new knob and push on until fully seated
• If knob does not seat, check shaft orientation and for debris—do not force into place

This adjustable buzzer kit replaces a failed or noisy mini buzzer to restore audible alerts for cycles, timers and notifications. Compact design lets the appliance signal you reliably when cycles finish or need attention. What it does:

• Produces audible tones for cycle end, timers and other appliance notifications
• Replaces buzzers that are silent, intermittent, weak or emitting erratic beeps
• Helps you hear and identify completed cycles and timed alerts
• Small, mountable unit that fits behind the control panel and connects to the control board

• One adjustable buzzer kit

• Disconnect power before servicing to avoid shock risk
• Access may require removing the control panel; keep fasteners organized for reassembly
• Disconnect the buzzer wiring harness or connector before removing the old unit; connect the new buzzer the same way
• Test buzzer function with power restored before fully reassembling

The Washer Timer is an OEM part for Whirlpool washing machines. It controls the various cycles and timing functions of the washer, ensuring that each cycle runs for the correct duration.

Causes of a bad washer timer can include wear and tear from regular use, electrical faults, or mechanical issues within the timer mechanism.

Symptoms of a bad washer timer include:

• The washer not advancing through cycles
• Incorrect cycle times or skipped cycles
• The washer stopping mid-cycle
• Inconsistent washing performance

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This hinge bracket secures a refrigerator door hinge to the cabinet, restoring proper door alignment and support so the door seals and closes reliably. Designed to replace a worn, bent, or broken hinge mounting bracket. What it does:

• Provides a stable mounting point for the door hinge assembly to prevent sagging or drooping
• Restores correct door alignment to improve sealing and reduce cold air loss
• Stops excess movement or rattling at the hinge area
• Helps eliminate door-binding or uneven gaps that keep the door from closing fully

• Unplug the appliance and remove food/items from the door before starting
• Support the door while removing/installing the bracket to avoid damage or injury
• Reuse or replace fasteners as required; tighten securely but avoid over-torquing
• After installation, check door alignment and gasket seal; make minor adjustments as needed

This motor connector housing is the molded body that holds the motor's wire terminals for a secure, insulated connection. Replacing a cracked or heat-damaged housing helps restore reliable motor operation and prevent intermittent power issues.

• Organizes and insulates the motor's wiring terminals
• Locks the harness to the motor for a firm electrical connection
• Helps reduce loose contacts, arcing, and heat damage at the plug
• If the housing is failing, you may see intermittent or no motor operation, the machine stopping mid-cycle, or visible melting/discoloration at the motor connector

• Disconnect power; also shut off gas supply
• Note wire positions; transfer terminals into the new housing one at a time to maintain orientation
• Inspect terminals and wiring; replace any burnt or loose terminals before reassembly
• Ensure the connector seats fully on the motor and the harness is secure; restore power and test

The Knob Spring Clip is an OEM part for Whirlpool appliances, specifically designed for use in washers and dryers. This small but essential component is responsible for securing the control knob to the control panel, ensuring that the knob stays firmly in place during operation.

Common causes of a bad spring clip include frequent use, accidental impacts, or wear and tear over time. A faulty spring clip can result in the control knob becoming loose or falling off, making it difficult to operate the appliance.

Symptoms of a bad knob spring clip include:

• The control knob is loose or wobbly
• The control knob falls off easily
• Difficulty in turning or setting the control knob
• The appliance not responding correctly to knob adjustments

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

A small retainer clip that secures panels, hoses or wiring to keep components in place and reduce noise from loose parts. Replacing a worn or broken clip restores proper fit and helps prevent intermittent contact or rattling. What it does

• Secures trim, panels, hoses or wire harnesses to mounting points to prevent movement.
• Keeps components aligned so switches and seals engage correctly.
• Stops rattling or vibrating noises caused by loose parts.
• Helps prevent abrasion or chafing of wires and hoses by holding them away from edges.

• Install by snapping or sliding the clip into the factory mounting slot; use needle-nose pliers if needed.
• Power off and unplug the appliance before accessing internal parts.
• Inspect surrounding mounts and mating tabs for damage; replace if worn for a secure fit.
• If removal is difficult, apply a small amount of penetrating lubricant and work carefully to avoid breaking adjacent plastic.
