Parts for Norge DEP223M: 03 - Tumbler Parts

Specs: 10-16 x 1/2 inch.

Seal assembly replaces the washer's front tub seal to prevent water from leaking around the cylinder, helping stop puddles under the machine and protecting internal components from water exposure. What it does:

• Forms a watertight seal between the front of the tub/cylinder and the outer housing.
• Helps stop leaks that occur during fill, wash, or spin cycles; replacement commonly resolves visible water at the front/base of the washer.
• Use when the seal shows cracks, tears, hardening, or other visible damage.
• Replacement restores proper sealing to help protect bearings and electronics from water intrusion.

• Disconnect power and turn off the water supply before servicing.
• Replacement typically requires front access and partial disassembly of the tub/cabinet; follow the manufacturer service manual and use appropriate tools.
• Clean and inspect the mating surfaces and the shaft for wear or contamination before installing the new seal.
• If you find bearing noise, oil residue, or extensive corrosion, consider replacing affected components.

The Screw is an OEM part for Whirlpool appliances that is responsible for securing various parts in place. The screw ensures a tight and secure fit, preventing any loose parts. A bad screw can occur due to wear and tear or accidental damage. If the screw becomes stripped, rusted, or lost, it can lead to instability or even malfunction of the affected parts.

Symptoms of a bad screw include:

• Loose or wobbly parts.
• Components not securely fastened.
• Difficulty in assembling or disassembling the appliance.
• Rattling or unusual noises during operation.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Get your dryer spinning smoothly again - install the Whirlpool 341241 OEM Drum Belt in minutes.

Why this belt?

• Exact factory spec: 92 ¼-inch length × ¼-inch width, 4 ribs / 3 grooves - built to Whirlpool standards, not a generic copy.
• Broad compatibility: Fits most Whirlpool-made dryers - Kenmore 110-series, Roper, Estate, Maytag, KitchenAid, Admiral, Crosley, Amana & more.
• Quiet, durable rubber: Reinforced EPDM resists cracking and stretch for years of reliable tumbling.

Fixes these common dryer problems

DIY install — about 15 minutes

1. Unplug dryer; remove lint screen housing & front panel.
2. Release belt tension at idler pulley; lift drum slightly to slide old belt off.
3. Loop new belt around drum, idler pulley and motor pulley (ribbed side down).
4. Re-assemble, run test cycle - enjoy quiet, consistent tumbling.

This rear support assembly stabilizes the appliance's rear housing and helps keep internal components aligned for smooth operation and reduced vibration. It restores proper rear-end support to prevent rubbing, noise, and uneven motion. What it does:

• Provides a stable mounting point for the appliance's rear section to maintain alignment
• Reduces vibration and rattling caused by a loose or worn rear support
• Helps prevent rubbing, scraping, or grinding noises from misaligned components
• Restores proper fit between the rear housing and moving parts to promote smooth operation

• One rear support assembly

• Disconnect power (and gas if applicable) before beginning any repair
• Access typically requires removing the appliance's rear panel or cabinet; follow OEM service manual steps
• Inspect surrounding mounting hardware and replace any worn fasteners for a secure fit

Size: 10-24 x 3/8 inch.

This retaining ring secures a component on a shaft or within a groove so it stays aligned during operation. Replacing a bent, rusted, or missing ring helps stop wobble, noise, and parts working loose.

• Locks into a groove to keep gears, pulleys, wheels, or spacers from sliding off a shaft
• Helps maintain proper spacing and alignment of moving parts
• Common signs of failure: wobbling parts, scraping/rubbing noises, or components that work loose
• Visual clues: deformation, corrosion, or loss of spring tension

• Disconnect power and any utilities to the appliance before service
• Wear eye protection—retaining rings can spring free under tension
• Note the order/orientation of any washers or spacers before removal
• Use appropriate snap-ring or needle-nose pliers and ensure the ring seats fully in its groove

Made for most Admiral, Crosley, Norge, and Magic Chef dryers. Kit includes 2 drum support rollers, 2 support shafts, 4 screws, 2 spacers, 2 washers, 2 retaining rings and instruction sheet.

This 10-24 threaded screw secures appliance components that use a #10 machine screw. It provides reliable fastening for panels, brackets, and assemblies so parts stay aligned and stable during normal use and service. What it does:

• Fastens panels, brackets, or assemblies that accept a 10-24 machine screw
• Maintains alignment and structural connection under normal operating loads
• Replaces worn, stripped, or missing screws to restore secure mounting
• Works with sheet-metal and component mating nuts or threaded inserts commonly used in appliances

• One 10-24 threaded screw

• Power tools can be used; avoid overtightening to prevent stripped threads or damaged components
• Disconnect power and follow all safety steps for your appliance before servicing
• Ensure proper engagement and torque to avoid damage

A 10-24 lock nut used to secure threaded fasteners and prevent loosening from vibration. Simple, durable replacement that restores proper fastening where the original nut has worn or failed. What it does:

• Secures shafts, studs, or bolts with 10-24 threads and resists loosening under normal appliance vibration.
• Restores proper tension where a stripped or loose nut causes rattling or parts shifting.
• Helps maintain alignment of panels, brackets, or components that rely on a locked fastener.
• Small hardware solution for common fastening failures—no special part modifications required.

• Disconnect appliance power and water before beginning repairs.
• Use the correct 10-24 threaded fastener and a properly sized wrench or socket to avoid rounding the nut.
• Tighten to a snug fit—do not overtighten or force onto damaged threads.
• Inspect mating threads and replace the bolt/stud if threads are stripped or damaged.

Size: 10-32 inch.
