Parts for Ge GDT680SSH7SS: Body Parts

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

The Door Spring is an OEM part for GE dishwashers. This part provides the necessary tension to the dishwasher door, allowing it to open and close smoothly and securely. The door spring helps balance the door’s weight, preventing it from falling open too quickly or slamming shut.

Causes of a bad door spring can include wear and tear from frequent use, stretching or breaking due to overloading the door, or damage from improper handling.

Symptoms of a bad Door Spring include:

• The door falling open quickly without resistance
• Difficulty in keeping the door open at a desired angle
• The door slamming shut instead of closing gently
• Unusual noises when opening or closing the door

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This leveling leg adjusts the dishwasher's height at the base, helping you level and stabilize the unit inside the cabinet. Proper leveling reduces rocking and vibration and promotes a tight door seal and smooth rack operation.

• Screws into the base frame to set height and level the dishwasher
• Supports the unit to prevent rocking or wobbling
• Helps maintain door alignment and sealing; poor leveling can contribute to leaks
• A worn, bent, or missing leg can make leveling difficult and increase vibration/noise

• Disconnect power and shut off water; slide the dishwasher out if needed for access
• Turn the leg with a wrench or pliers to adjust height; replace by threading the new leg into the base
• Use a bubble level to set side-to-side and front-to-back level before re-securing the unit
• Do not overtighten; ensure both legs carry weight evenly on a solid floor surface

The Heating Element is an OEM part for GE dishwashers. It is responsible for heating the water during the wash cycles and for drying the dishes after the rinse cycle. Proper functioning of the heating element ensures optimal cleaning and drying performance.

Causes of a bad heating element can include mineral buildup from hard water, electrical faults, or general wear and tear over time. Damage to the heating coil or connections can also impair its functionality.

Symptoms of a bad heating element include:

• Dishes not drying properly
• Dishwasher cycles taking longer than usual
• Water not heating during the wash cycle
• Error codes related to heating issues

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This leak pan is the factory replacement drip/overflow tray that catches and channels unwanted water away from the appliance to help prevent damage to floors and cabinetry. Fits where the original pan collected condensation or small leaks. What it does:

• Catches water from minor leaks, condensation, or defrost drain overflow
• Directs collected water to the appliance drain path or containment area
• Helps prevent water from reaching flooring and cabinetry
• Common symptom: water pooling under or around the appliance

• Disconnect power and water supply before beginning any service
• Access typically requires removing the appliance kickplate or lower access panel
• Inspect and clear associated drain lines and gaskets while replacing the pan

The screw is an OEM replacement component for GE dishwashers. It is used to securely fasten parts inside the dishwasher tub assembly.

Causes of a damaged or defective screw usually involve wear from continuous mechanical stresses and vibration during dishwasher usage. Loose parts affect machine balance and performance.

Symptoms of a compromised screw placement include:

• Noises or abnormal sounds coming from inside the tub
• Intermittent error codes related to moving components
• Detached or misaligned spray arms or filters
• Insecure tub fixtures that can be jarred with normal operation

This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This high loop drain hose creates the required elevated drain loop to help prevent dishwasher backflow and ensure proper drainage. It replaces a worn or damaged drain loop and restores correct drain routing for reliable performance. What it does:

• Forms the high loop in the dishwasher drain line to reduce risk of sink water siphoning back into the appliance
• Directs wastewater from the dishwasher into the household drain properly
• Helps avoid intermittent draining issues caused by a collapsed or split drain loop
• Fits into existing drain connections—used where an elevated drain loop is required

• Designed for in-line replacement; route the hose to create a high loop secured under the countertop or cabinet as shown in the appliance installer instructions
• Turn off power and water supply to the appliance before performing service
• Inspect clamps and fittings and replace if corroded; ensure all connections are snug but not over-tightened

The Upper Spray Arm is an OEM part for GE dishwashers. It is designed to distribute water evenly throughout the upper rack during the wash cycle, ensuring that all dishes are thoroughly cleaned. The spray arm rotates to provide coverage and spray patterns that reach every dish and utensil. The arm measures about 10 inches by 2.5 inches

Over time, the upper spray arm can become clogged with food particles or mineral deposits, which can impede its function. Physical damage or wear and tear can also cause it to fail.

Symptoms of a bad upper spray arm include:

• Dishes on the upper rack not getting clean
• Reduced water pressure from the upper arm
• Spray arm not spinning or moving properly
• Visible cracks or damage to the spray arm

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Fill Funnel Service Kit is an OEM replacement part for GE dishwashers. It contains the funnel assembly and seal/gasket used for the water inlet. Reliable filling is important for effective cleaning.

Causes can be cracks, tears, or deformities developing in seals over extended use periods. Mineral buildup may also compromise sealing surfaces.

Symptoms of a bad service kit include:

• Water leaks from around the inlet area
• Inconsistent water filling during dishwasher cycles
• Damp residue or puddles below inlet assembly

This is a genuine OEM part that works for some models of GE, and Hotpoint models.

The Fill Funnel Service Kit is an OEM replacement part for GE dishwashers. It contains the funnel assembly and seal/gasket used for the water inlet. Reliable filling is important for effective cleaning.

Causes can be cracks, tears, or deformities developing in seals over extended use periods. Mineral buildup may also compromise sealing surfaces.

Symptoms of a bad service kit include:

• Water leaks from around the inlet area
• Inconsistent water filling during dishwasher cycles
• Damp residue or puddles below inlet assembly

This is a genuine OEM part that works for some models of GE, and Hotpoint models.

This dishwasher fill hose routes incoming water from the inlet valve into the tub. Replacing a brittle or leaking hose helps restore proper filling and reduces the risk of water leaks under the unit.

• Carries fresh water from the inlet valve to the dishwasher during the fill cycle
• Helps maintain correct water level for reliable wash performance
• Common symptoms of a failed hose: leaks near the toe kick, slow fill, or no fill
• Replaces hoses that are cracked, swollen, kinked, or deteriorated

• Disconnect power and shut off the water supply before service
• Place a towel or shallow pan to catch residual water
• Access behind the lower kick panel; transfer existing clamps/fittings as needed
• Route the hose without kinks, fully seat connections, restore water, and check for leaks during a test cycle

The Fill Funnel Service Kit is an OEM replacement part for GE dishwashers. It contains the funnel assembly and seal/gasket used for the water inlet. Reliable filling is important for effective cleaning.

Causes can be cracks, tears, or deformities developing in seals over extended use periods. Mineral buildup may also compromise sealing surfaces.

Symptoms of a bad service kit include:

• Water leaks from around the inlet area
• Inconsistent water filling during dishwasher cycles
• Damp residue or puddles below inlet assembly

This is a genuine OEM part that works for some models of GE, and Hotpoint models.

The Conduit Main Assembly is an OEM replacement part for GE dishwashers. It is installed within the dishwasher tub below the upper wash arm, and is responsible for securely mounting and holding the upper wash arm in place during operation.

Causes of a bad upper wash arm support include:

• Symptoms of a bad upper wash arm support include:
• Vibration or noise from an unsecured wash arm
• Improper alignment of spray pattern
• Restricted rotation of the wash arm during washing
• Leaks at the tub connection point

Symptoms can include cracks or breaks that compromise its structure, or wear over extended use without replacement.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This conduit seal fits the dishwasher's water-feed conduit connection, keeping wash water contained and pressure steady to the spray arms. Replacing a worn seal helps address leaks and maintain reliable cleaning performance.

• Seals the joint where the dishwasher's water feed conduit/tube connects within the wash system
• Helps prevent water leaks at the conduit connection point
• Maintains proper wash pressure for consistent spray performance
• Common signs of failure: drips beneath the unit, visible cracks/flattening, or a loose-fitting old seal

• Disconnect power and shut off the water supply before servicing
• Access the conduit connection (location varies by model), remove the old seal, and clean mating surfaces
• Lightly moisten the new seal to ease installation and seat it fully
• Reassemble and run a brief cycle to check for leaks

The Door Cable is an OEM part for GE dishwashers, designed to support and assist in the smooth and controlled opening and closing of the dishwasher door. This cable connects the door to the spring mechanism, providing the necessary tension to balance the door's weight during operation.

Signs that you might need to replace the Door Cable include the door suddenly dropping open or being difficult to raise, indicating a break or excessive wear.

Symptoms of a bad Door Cable include:

• The dishwasher door slamming open or requiring extra force to close.
• Unusual noises when opening or closing the door, suggesting the cable is not running smoothly.
• Difficulty in keeping the door partially open, affecting loading and unloading dishes.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 8-32 t. Includes 12 screws.

This front tub spacer cushions and positions the washer tub to reduce vibration and keep the inner and outer tubs properly aligned during operation. It helps maintain smooth spin cycles and prevents metal-to-metal contact. What it does:

• Centers and supports the front of the washer tub to maintain proper drum alignment
• Absorbs movement to reduce vibration and noise during spin
• Prevents rubbing or contact between the tub and cabinet components
• Can be associated with symptoms like excessive vibration, rubbing sounds, or off-center spins

• Designed for direct replacement; inspect surrounding seals and mounts during service
• Use basic hand tools; follow the washer's service manual for safe disassembly and reassembly
• Disconnect power and water supply before beginning any repair

This dishwasher junction box cover encloses the power-connection compartment at the base of the unit. Replacing a damaged or missing cover helps protect wiring from debris and accidental contact, restoring a safe, secure connection area. What it does:

• Covers and secures the dishwasher's electrical junction box
• Helps shield wire splices from moisture, dust, and accidental contact
• Restores proper fit when the original cover is cracked, broken, or missing
• Useful if the junction box won't stay closed or the cover no longer secures properly

• Includes 1 junction box cover

• Disconnect power at the circuit breaker before servicing
• Remove the lower access/kick panel to reach the junction box
• Remove the old cover and screw, position the new cover, and secure with the existing hardware
• Ensure all wiring and the strain relief are fully inside the box before closing; restore power and test

The Water Inlet Valve is an OEM part for GE dishwashers. This part controls the flow of water into the dishwasher. It opens and closes to allow water from the home's supply to enter the dishwasher at the correct times during the washing cycle.

Causes of a bad water inlet valve include wear and tear from regular use, sediment buildup from hard water, or mechanical failure of the valve components.

Symptoms of a bad Water Inlet Valve include:

• Dishwasher not filling with water
• Water filling too slowly or not stopping once the dishwasher is full
• Leaks detected around the valve area
• Unusual noises coming from the valve during the fill cycle

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

The Electronic Control Board Jumper Wire is an OEM replacement part for GE dishwashers.

Causes of a faulty jumper wire include fracturing of internal interconnects from normal circuit board flexing during door closes. Overly aggressive cleaning solvents may also damage wire insulation over time.

Symptoms of a problematic jumper wire include:

• Intermittent or unreliable operation of wash cycle features
• Unresponsive touch controls and inability to start cycles
• Error codes displayed and failure to detect cycle outputs

This is a genuine OEM part that works for some models of GE, and Hotpoint models.

The Electronic Control Board is an OEM part for GE dishwashers. As the central processing unit, it monitors and orchestrates all washing functions including temperature, spray arms, and the precise dishwasher cycles.

Causes can be moisture damage, power surges over the years, or natural degradation. Replace it with this genuine GE control board to restore optimized cleaning and sanitization along with long-term reliability.

Symptoms of a bad control board include:

• Failure to start or complete cycles
• Unusual noises or rattling sounds mid-cycle
• Inability to select different wash options
• Erratic temperature or inconsistent water levels

This GE replacement part is compatible with Hotpoint, RCA, and some Kenmore models.


This wiring harness assembly connects DC-powered components to the appliance's control system, restoring reliable electrical and signal paths for proper operation. It replaces a damaged or worn harness so circuits can function safely. What it does:

• Routes power and signal connections between the control board and DC-driven components
• Provides secure, keyed connectors to prevent mis-mating and intermittent contacts
• Helps stop failures caused by frayed wires, broken terminals, or melted insulation
• Common symptom fixes: appliance won't start or runs intermittently, loss of motor power, or electrical error codes

• Disconnect power to the appliance before beginning any service
• Inspect connectors and wire routing; replace if insulation or terminals are damaged
• Route and secure the harness per OEM routing to avoid heat and abrasion

This dielectric shield is a small heat-resistant insulator that protects ignition wiring and components from heat and prevents electrical arcing near burners. It helps maintain reliable spark ignition and reduces risk of shorts or damage from high temperatures. What it does:

• Shields spark module wires and electrode areas from direct heat exposure
• Helps prevent arcing and electrical shorts that can interrupt ignition
• Reduces risk of melted or damaged wire insulation near burners or ovens
• Commonly replaced when cracked, deformed, or showing burn marks that affect ignition

• Disconnect power (and gas if applicable) before servicing electrical or ignition components
• Inspect surrounding wiring and connectors; replace any damaged insulation or terminals
• Reinstall using original mounting hardware and ensure the shield fully covers the wire/electrode area

This control box bottom is the lower housing that protects and supports the appliance's control electronics, helping keep wiring and components secure from debris and moisture. Fits into the control assembly to restore proper enclosure and support. What it does:

• Provides a protective lower enclosure for the control board and wiring harness
• Helps keep dust, lint and moisture away from sensitive electronics
• Secures the control board and related connectors in their correct position
• Prevents rattling or movement that can cause loose connections or noise

• One control box bottom (base cover) as pictured

• Disconnect power before servicing to avoid shock or component damage
• Handle electronics carefully and avoid touching circuit contacts
• Installation typically requires basic hand tools and removal of the control housing

Replacement control box top that restores the protective cover for the appliance control housing, keeping wiring and electronics enclosed for a cleaner appearance and safer operation. What it does:

• Covers and protects the control housing and internal wiring from dust, spills, and accidental contact
• Helps secure control components in place and maintain the appliance's factory appearance
• Commonly replaced when the original cover is cracked, broken, missing, or shows visible damage
• Can prevent loose wiring from catching or being accidentally disturbed

• One control box top

• Disconnect power to the appliance before beginning any work to avoid shock or injury
• Remove any screws or retainers securing the existing cover and lift off the old top; keep fasteners if reinstalling
• Align the replacement top and secure with the original fasteners; ensure wiring is routed and seated before closing

Size: 10-16 ab.

This hose clamp kit secures the washer's hoses at the pump, tub, or valve connections, helping stop leaks and hose blow-offs. Replace worn or missing clamps to restore a tight, reliable seal during fill, wash, and drain.

• Secures drain, pump, and fill hoses to fittings to maintain a watertight seal
• Helps prevent drips, leaks, and hoses slipping off during vibration
• Replaces clamps that are rusted, stripped, deformed, or missing
• Common symptoms: water leaking at hose joints, loose hose connections, clamp won't tighten
• Useful when installing a new hose, pump, or valve

• Unplug the washer and turn off water supplies; have towels or a pan ready for residual water
• Release and remove old clamps; seat the hose fully over the fitting before installing new clamps
• Tighten evenly and do not overtighten to avoid hose or fitting damage
• Restore power and water, then run a short cycle to check for leaks at each connection

The Clamp is an OEM replacement part for GE dishwashers. It holds and secures critical components such as tubing or hoses securely in place. Clamps play an important supporting role by fastening tubing and preventing kinking, both of which are essential for proper water flow and circulation within the dishwasher.

Causes of a bad clamp can include cracks, corrosion, or fatigue that causes the clamp to fail in its gripping function over time. Hoses or tubes may also wear down a clamp through constant vibration.

Symptoms of a bad clamp include:

• Leaks from hoses, tubes or connections
• Reduced water pressure or uneven spray patterns
• Moisture or water damage around connections
• Loose hoses that rub or chafe

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 10-32 GXTT FLP.595 S

The Door Latch is an OEM replacement part for GE dishwashers. It serves the critical function of securely keeping the door closed during wash cycles through its engaging bolt design.

Over extended use, aspects of the latch can degrade such as worn plastic catch areas, loosened screws, or a faulty latch hook mechanism. Causes are generally normal wear and tear.

Symptoms of a bad latch include:

• The door not closing fully or popping open accidentally
• Inability to fully lock or latch no matter how hard the door is pressed
• Damaged or stripped screws holding the mechanism

This OEM replacement part is compatible with Hotpoint, RCA and some Kenmore models as well.

This flexible door gasket seals the dishwasher tub opening to keep wash water inside the cabinet. Replace a worn or flattened gasket to stop leaks and restore a tight, quiet door seal.

• Compresses between the door and tub to prevent water from escaping during wash and rinse cycles
• Helps reduce moisture at the front corners and under the door
• Common failure signs: water leaking at the bottom/front of the door, visible tears, cracks, or permanent flattening of the seal
• Can also help if the door feels loose or doesn't seal evenly

• Disconnect power and turn off water before service
• Open the door and pull the old gasket straight out of the groove; clean the channel of debris and buildup
• To ease installation, warm the new gasket to relax it, then press it into the channel starting at the top center and work evenly down both sides
• Close the door for several minutes to help seat the new seal, then run a short cycle to check for leaks

This tub top trim replaces the decorative/top trim that surrounds the washer tub opening to restore a finished look and help keep the inner tub sealed from the cabinet. It's a direct-fit exterior trim piece for top-load washers. What it does

• Replaces damaged, cracked, or warped tub top trim that lets water spray toward the cabinet
• Restores the washer's finished appearance around the tub opening
• Helps keep the tub's edge covered to reduce splash and debris entry
• Useful when the original trim is loose, bent, or cosmetically worn

• One tub top trim piece as shown

• Turn off power and water to the washer before beginning any service
• May require removing the cabinet or control console depending on model; follow the OEM service instructions
• Use proper fasteners and gaskets from the OEM parts list if required; only install what is included

Restore a clean, finished look at your dishwasher's tub opening with this tub trims kit. Replacing worn or missing side trims helps the door open and close smoothly and prevents snagging or rubbing along the tub edges.

• Finishes and protects the left and right edges of the tub opening
• Helps guide the door and maintain proper clearance
• Replace if trims are cracked, warped, missing, loose, or discolored
• Common signs include visible gaps, trim falling off, or door scraping/binding

• Disconnect power and turn off the water supply before servicing
• Open the door, remove old trims, and clean the mounting surfaces
• Align each new trim to the correct side and press/seat fully for a secure fit
• Open and close the door to confirm smooth operation and proper clearance

The Mounting Bracket is an OEM replacement part for GE dishwashers. This bracket secures the dishwasher in place underneath the kitchen countertop.

Causes of failure relate to stresses of a heavy dishwasher pushing down against the countertop edges combined with constant machine vibration over extended service life.

Symptoms of a cracked or damaged mounting bracket include:

• Excessive movement play or sloshing of the installed dishwasher
• Strange noises when the dishwasher is running
• Difficulty removing or installing the dishwasher
• Visible bending of bracket components out of intended position

This genuine GE bracket is compatible with Hotpoint and RCA dishwashers.

The Countertop Screw & Buttonplug is an OEM part for GE dishwashers. This assembly includes screws and button plugs designed to securely fasten the dishwasher to the underside of kitchen countertops.

Causes of a bad Countertop Screw & Buttonplug can include stripped threads from over-tightening, corrosion due to exposure to moisture, or general wear and tear that diminishes the screws' and plugs' ability to maintain a secure hold.

Symptoms of a bad Countertop Screw & Buttonplug include:

• Dishwasher tilting forward when the door is opened
• Visible gaps between the dishwasher and countertop
• Loose feeling or movement of the dishwasher when pushed
• Screws failing to hold or remain in place

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This control board clip secures the dishwasher's electronic control board to its mounting location, keeping it properly seated during operation. Replacing a damaged or missing clip helps prevent vibration, movement, and wire-connector strain.

• Holds the electronic control board firmly in its designated mount or housing
• Helps prevent board movement, rattling, and connector stress from vibration
• Replace if the clip is cracked, deformed, or missing
• Symptoms include a loose control assembly, rattling noises, or a board that won't stay seated

• Disconnect power at the breaker before servicing
• Access the control area; support the board when removing/installing the clip
• Handle the control board by the edges and observe ESD precautions
• Ensure the new clip is fully seated and the board is secure before reassembly

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces
