Parts for Lg WM3170CW / 00: Drum Parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

This washer drum lifter (baffle) mounts inside the drum to raise and tumble clothes as the basket turns. Replace a cracked or missing lifter to restore wash action, help protect fabrics, and reduce rattling noises.

• Attaches to the inner drum and lifts garments during rotation for effective tumbling
• Helps distribute loads and improve mechanical cleaning action
• Direct replacement for lifters that are cracked, loose, sharp-edged, or missing
• Typical symptoms: poor tumbling/wash results, thumping or rattling from the drum, clothing snags or tears, lifter wobbling or fallen off

• Disconnect power and turn off water supply before servicing
• Open the door and rotate the drum to access the lifter
• Depending on model, release locking tabs from inside the drum or remove the retaining fastener; align and secure the new lifter
• Ensure the lifter is fully seated and secure; run a short rinse/spin to verify proper operation

This bolt assembly is the shipping bolt used to secure a washing machine's tub and suspension during transport. Replacing a missing or damaged bolt helps protect internal components from vibration and impact when moving the appliance. What it does:

• Locks the tub in place to limit movement during shipping or relocation
• Helps prevent internal damage caused by excessive shaking in transit
• Restores a complete set when one shipping bolt is lost, bent, or stripped
• For transport only—remove all shipping bolts before operating the washer

• 1 bolt assembly

• Unplug the appliance and shut off water before starting
• From the rear, align the bolt with the shipping hole and hand-thread to avoid cross-threading; tighten securely without overtightening
• Install all shipping bolts required by your model (often four) before moving the unit
• After moving, remove all shipping bolts before use and store for future moves

The Bearing Ball is an OEM part for LG washing machines. This component plays a crucial role in the smooth operation of the washer drum, enabling it to rotate quietly and efficiently during the wash and spin cycles.

Causes of a bad bearing ball can include regular wear and tear, exposure to heavy loads, or insufficient lubrication. Over time, these factors can lead to deterioration and reduced performance of the bearing ball, potentially causing the washer drum to spin improperly or not at all.

Symptoms of a bad bearing ball include:

• Loud rumbling or grinding noises during the wash or spin cycles
• The drum not spinning or spinning unevenly
• Increased vibration or movement of the washer
• Leaks from the drum area due to damaged seals

This OEM LG part is also compatible with Sears/Kenmore models.

The Ball Bearing is an OEM part for LG washing machines. It is designed to support the drum's rotation within the washer, ensuring smooth and quiet operation during the wash and spin cycles. This ball bearing helps reduce friction and wear, contributing to the overall efficiency and longevity of the appliance.

Causes of a bad Ball Bearing can include excessive wear due to heavy use, exposure to water or detergent leading to rust or corrosion, or damage from an unbalanced load. Over time, the bearing can degrade, leading to operational issues and increased noise.

Symptoms of a bad Ball Bearing include:

• Loud, unusual noises during the spin cycle
•  The drum not rotating smoothly
• Excessive vibration or shaking
• Leaking from the drum area

This OEM LG part is also compatible with select Sears/Kenmore models.

This factory bolt assembly fastens critical components securely inside your appliance. Replacing a worn, stripped, or missing bolt restores a snug fit, reduces vibration and noise, and helps prevent damage caused by loosening during operation. What it does:

• Secures mating parts to maintain alignment and structural stability
• Helps prevent vibration, rattling, and movement from a loose fastener
• Addresses issues like wobble or intermittent operation in the affected area
• Replaces damaged, corroded, or missing hardware for a reliable hold

• One bolt assembly

• Disconnect power before servicing
• Support the assembly being fastened to avoid strain or misalignment
• Start threads by hand to prevent cross-threading; tighten snugly without overtightening
• Replace companion washers or hardware if worn or damaged; match any threadlocker used on the original

The Rear Tub Gasket is an OEM part for LG washing machines. It provides a watertight seal between the rear tub and the front tub assembly, preventing water leaks during the wash and spin cycles. This gasket ensures that water remains contained within the drum, contributing to the overall efficiency and performance of the washing machine.

You should replace the rear tub gasket if it becomes worn out, cracked, or damaged. Causes of a bad rear tub gasket can include general wear and tear, mold or mildew buildup, and damage from foreign objects during washing.

Symptoms of a bad rear tub gasket include:

• Water leaking from the back of the washing machine
• Visible cracks, tears, or deformation in the gasket
• Mold or mildew buildup around the gasket area
• Unusual noises during the wash cycle indicating a loose or misaligned gasket

This OEM LG part is also compatible with certain models of Kenmore washing machines.

This Screw (drawing) is a factory fastener used to secure appliance panels and components. Replacing a stripped, corroded, or missing screw restores a tight fit, reduces vibration, and helps keep assemblies correctly aligned.

• Secures panels, brackets, and mounting points as specified by the manufacturer
• Replaces screws that are lost, damaged, corroded, or stripped
• Helps address rattling, vibration, or loose-fitting parts caused by missing hardware
• Maintains proper alignment and stability of the assembly

• Disconnect power and, if applicable, shut off gas/water before servicing
• Match the screw to its original location; start threads by hand to avoid cross-threading
• Use the correct driver; tighten snugly without over-torquing into metal or plastic
• Refer to your model's parts diagram to correct location and quantity

This balance weight secures to the appliance frame to add counterweight where needed, helping reduce vibration and stabilize moving parts for quieter, more reliable operation. What it does:

• Adds counterbalance to a drum, door or other moving component to reduce shaking and excessive movement during operation.
• Restores proper weight distribution to prevent off-balance conditions that can trigger vibration or noise.
• Typically fastens to the frame with mounting bolts to transfer and even out dynamic loads.
• A worn, loose or missing balance weight may be linked to loud banging, heavy vibration or uneven operation.

• Disconnect power (and water supply for washers) before starting any repair.
• Remove the appropriate access panels to reach the mounting location; keep fasteners for reassembly.
• Reinstall using the original mounting bolts and follow OEM torque recommendations when available.
• Inspect adjacent suspension, mounts and hardware while servicing.

The Outer Tub Gasket is an OEM replacement part for LG front-load washers. Situated between the front and rear outer tubs, it forms a critical seal preventing water leaks during fills and cycles. Constructed from durable yet flexible rubberized material, this gasket withstands constant compression from tub movements.

Causes for replacement are cracks developing from years of flexing stresses, as well as distortions that compromise sealing integrity. Normal seal compression can also cause gradual wear of sealing material over time.

Symptoms of a faulty front-load outer tub gasket include:

• Puddles or drips of water between or behind the wash tubs
• Dried mineral deposits from leakages around tub connection points

This OEM LG part is also compatible with some Sears/Kenmore.

A standard replacement bolt used to secure appliance panels and internal assemblies. This OEM-style fastener restores proper fit and reduces movement that can cause noise or misalignment in appliance components. What it does:

• Fastens panels, brackets, and components to maintain structural integrity
• Keeps moving parts aligned to help prevent rattling or vibration
• Replaces missing, loose, or corroded bolts that compromise fit
• Suitable where a standard machine/sheet-metal bolt is required

• One bolt

• Disconnect power and water before servicing the appliance
• Use the correct driver/socket to avoid stripping the head or threads
• Tighten securely but avoid over-torquing; replace any damaged nuts or washers
• Inspect mating threads and clean or chase threads if corroded

The wire harness links appliance components and restores a dependable electrical connection. Replace a damaged or burnt harness to correct intermittent operation or loss of function in the affected circuit. What it does:

• Routes power and signals between internal components
• Replaces cut, heat-damaged, or brittle wires and connectors
• Helps resolve intermittent operation or no response from the connected part
• Restores continuity when terminals are loose or corroded

• One single wire harness

• Disconnect power before servicing; if your appliance is connected to water, shut off the supply as applicable
• Photograph routing and connections before removal to match the original layout
• Route the new harness exactly like the original; keep clear of sharp edges, heat sources, and moving parts
• Fully seat connectors without forcing; ensure locking tabs engage

The Float Assembly is an OEM part for LG washing machines. This part monitors and controls the water level within the appliance. It's a safety feature that prevents water overflow and potential flooding, contributing to the efficient operation of the washing machine by maintaining the correct water level for each cycle.

Causes of a bad Float Assembly can vary from simple blockages that prevent the float from moving freely to electrical faults within the switch mechanism.

Symptoms of a bad Float Assembly include:

• Water overflowing from the washing machine
• Inadequate water levels that affect the washing cycle's effectiveness
• The washing machine failing to start the fill cycle due to a malfunctioning float switch

This OEM LG part is also compatible with some Kenmore models.

The Dispenser Hose is an OEM part for LG washing machines. It connects the detergent dispenser to the washer tub, allowing detergent and other cleaning agents to be delivered effectively during the wash cycle.

Causes of a bad dispenser hose can include regular wear and tear, damage from harsh detergents, or physical damage due to kinks, pinches, or impact. Over time, the hose can become brittle, cracked, or clogged, affecting its ability to function properly.

Symptoms of a bad dispenser hose include:

• Leaks or drips from the hose area
• Detergent not dispensing correctly or at all
• Water pooling around the washer
• Visible cracks or splits in the hose

This OEM LG part is also compatible with Sears/Kenmore models.

The Vent Hose is an OEM part for LG washing machines. This hose is essential for ensuring proper ventilation within the washer, allowing air to circulate and preventing the buildup of moisture and mildew. It helps maintain the efficiency of the washing machine by facilitating the expulsion of air and excess water vapor during operation.

Causes of a bad washer vent hose can include wear and tear over time, blockages from lint or debris, or damage due to bending or pinching.

Symptoms of a bad vent hose include:

• Excessive moisture or condensation inside the washer
• Musty odors from the washing machine
• Visible cracks or holes in the hose
• Poor ventilation leading to inefficient washing cycles

This OEM LG part is also compatible with Sears/Kenmore.

The Drain Pump and Motor is an original LG (OEM) replacement part for LG made washing machines that is responsible for removing water from the washer at the end of the wash cycle. The pump forces water out through the drain hose so that clothing comes out free of excess water, making the drying process faster.

Symptoms of a failing Drain Pump Motor include:

• Water not draining out of the washing machine
• Noisy or unusual sounds coming from the pump area during the drain cycle
• The washing machine stopping mid-cycle

Causes of a bad Drain Pump Motor can range from obstructions in the pump or hose, which can strain or damage the motor, to wear and tear from regular use leading to motor failure. Electrical issues can also affect the motor's performance, preventing it from operating correctly.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Pump Casing is an OEM replacement part for LG washing machines. It is a crucial component that houses the drain pump, which is responsible for removing water from the wash tub during the drain and spin cycles.

Symptoms of a need to replace the pump casing:

• Leaks or water seeping from the pump area
• Unusual noises or vibrations during the drain or spin cycles
• Pump failure or inability to drain water effectively
• Cracks or damage to the casing itself

Causes of a faulty pump casing can include physical impact or mishandling, excessive wear and tear over time, or potential manufacturing defects.

This OEM LG part is also compatible with Sears/Kenmore washing machines.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

The Stator Assembly is an OEM replacement part for LG washing machines. It is an electrical component inside the motor that converts rotational motion to electrical energy to power spinning motions.  Note: For the RPS or Hall Sensor, order part number AP7015078.

Symptoms of a faulty stator include:

• Slow or inefficient spinning, rubbing noises
• The machine failing to fully drain or spin clothes
• Repeated blowouts or failure of related motor components

Causes can be wear and tear over extended use. Environmental factors like dust and moisture exposure may degrade insulation integrity.

This OEM stator is also compatible with some Kenmore front-load washer models.

This is the direct-drive rotor for the dishwasher wash motor. It pairs with the stator to spin the impeller and circulate wash water through the spray arms, helping restore proper spray pressure and quieter operation when the original rotor is worn.

• Couples with the stator to drive the circulation pump impeller
• Moves wash water through the spray arms for consistent cleaning performance
• Common failure signs: little or no spray, poor cleaning, loud humming or grinding from the pump area, or intermittent wash action
• Physical damage or weakened magnets can prevent proper rotation

• Disconnect power and water supply and pull the unit forward for access
• Remove the toe-kick and drain remaining water at the sump
• Remove the pump cover and center fastener, then pull the old rotor straight off
• Seat the new rotor fully, reassemble, and run a test cycle to check operation and leaks

This hinge spring restores proper door tension so the appliance door opens and closes smoothly and stays in position. Replacing a worn spring reduces sagging, uneven closing, and noisy or slamming doors. What it does:

• Provides tension at the hinge to hold door position and improve alignment
• Helps prevent door sagging and uneven gaps caused by worn springs
• Reduces slamming, popping, or grinding sounds during door movement
• Common symptom: door won't stay open/closed or feels loose at the hinge

• Disconnect power and unplug the appliance before starting any repair
• Support the door while removing/installing the spring to prevent it from dropping
• Basic hand tools (screwdriver, pliers) are typically needed; follow the appliance's service guide

This tub clamp secures the washer tub assembly or related hoses to keep components aligned and reduce movement during operation. It helps restore proper fitment so the tub stays stable and functions quietly. What it does:

• Holds the tub or tub-related components in place to prevent shifting during cycles
• Helps reduce vibration and noise caused by loose tub mounting
• Maintains correct alignment of hoses and seals to reduce leak risk
• Used when a worn or broken clamp allows excessive tub movement

• One tub clamp

• Turn off power and water supply before beginning any repair
• Inspect surrounding components (hose, seal, mounting points) and replace if damaged
• Use common hand tools; secure clamp evenly to avoid twisting the tub or hoses

The Gasket is an OEM part for LG washing machines, designed to create a watertight seal between the door and the machine's body. This part prevents water from leaking out during the washing cycle. Over time, however, the gasket can wear down, lose its elasticity, or become damaged, leading to leaks and potential water damage. Causes of a bad gasket can range from natural wear and tear over time.

Symptoms of a bad Gasket include:

• Water leaking from the door
• Visible signs of wear, such as cracks or holes
• Mold or mildew on the gasket
• Difficulty closing the door

This OEM LG part can also be used on Kenmore/Sears appliances.

A molded water guide that routes dispenser water inside the refrigerator to the dispenser/ice area, helping direct flow and reduce splashing. Fits the factory mounting points for a clean, secure path for water. What it does

• Channels water from the inlet tubing toward the dispenser/ice assembly to prevent misdirected flow.
• Helps keep water from pooling or dripping inside the cabinet or on internal components.
• Common replacement when you see water on shelves, puddling near the dispenser, or reduced or misdirected dispenser flow.
• Preserves proper alignment of the dispenser plumbing to prevent kinks or strain on tubing.

• One water guide (single molded channel) as shown.

• Turn off the refrigerator and shut off the water supply before starting; disconnect power for safety.
• Remove interior panels or shelves as needed to access mounting points; keep fasteners for reassembly.
• Inspect adjoining tubing and seals for damage and replace any worn components to ensure a leak-free fit.
• After installation, restore power and water, then check carefully for leaks during an initial test dispense.

The Tub to Pump Hose is an OEM replacement part for LG top-load washing machines. This hose safely transports water between the wash tub and drain pump. The hose measures 13 inches in length.

Causes of failure relate to constant flexing under water pressure strains that accumulate over years of usage. Excess minerals in hard water areas promote accelerated breakdown of flexible PVC material.

Symptoms of a cracked or leaking tub to pump hose include:

• Water not draining or taking an abnormally long time
• Water continually accumulating inside the machine cabinet
• Error codes related to drainage issues displayed
• Puddles forming near or under the back of the washer

This genuine LG hose is also compatible with select Sears/Kenmore units as well.

The Inner Door Boot Seal Clamp is an OEM part for LG washing machines. The clamp's primary function is to secure the door boot seal in place, preventing leaks during the wash cycle.

Causes of a bad Inner Door Boot Seal Clamp can include corrosion due to exposure to moisture and detergent, loss of tension over time, or physical damage which can lead to a compromised seal.

Symptoms of a bad Inner Door Boot Seal Clamp include:

• Water leaking from the front of the washing machine
• Visible rust or damage on the clamp
• The door boot seal coming loose or falling off

This genuine LG OEM replacement part is also compatible with some Kenmore models.

The Air Chamber is an OEM part for LG washing machines. This part connects to the pressure switch and ensures the washer machine fills with the correct amount of water for the selected cycle.

Causes of a bad  Air Chamber can include clogging due to detergent residue or debris, cracks or perforations that lead to air leaks, and aging of the material, which might compromise its integrity and function.

Symptoms of a faulty Air Chamber include:

• Inaccurate water level readings leading to overfilling or insufficient water during cycles
• Unusual noises during the fill cycle, indicating air escaping
• The washing machine failing to start the wash cycle due to improper water level detection
• Error codes displayed on the machine that relate to water level issues

This OEM LG part is also compatible with some Kenmore models.

The Hose is an OEM part for LG washing machines. This component is crucial for the proper flow of water into and out of the washing machine, ensuring efficient washing and rinsing cycles. The hose is designed to withstand high water pressure and regular use.

Causes of a bad hose can include wear and tear over time, exposure to harsh water conditions, or accidental damage such as kinks or punctures. Ensuring the hose is in good condition is essential to prevent leaks and maintain optimal water flow.

Symptoms of a bad hose include:

• Water leaks around the hose connections
• Reduced water flow into or out of the washing machine
• Visible cracks, bulges, or kinks in the hose

This OEM LG part is also compatible with Sears/Kenmore.

This connector hose replaces the appliance's water connection to restore secure water flow and reduce the risk of leaks or interrupted dispenser/ice-maker operation. It's a direct replacement for a damaged or leaking supply connector. What it does:

• Connects the household water supply to the appliance's internal water valve or dispenser.
• Restores reliable water flow when a cracked, split, or collapsed hose prevents proper delivery.
• Reduces water leakage caused by worn or damaged connector ends and seals.
• Commonly needed when you see visible leaks, no water to the dispenser/ice maker, or a loose/broken hose connection.

• Turn off water supply and unplug the appliance before replacing the hose to avoid electric shock or water damage.
• Use proper clamps and fittings; make sure connections are seated and tightened just enough to stop leaks—do not overtighten.
• After installation, restore power and water, then check all connections carefully for leaks. Replace immediately if the hose or fittings show signs of damage.

This clamp assembly secures a hose or tubing connection to maintain a watertight seal and reduce vibration. Replacing a worn or damaged clamp helps stop leaks and prevents hoses from slipping loose during operation. What it does:

• Holds a hose or tube firmly in place to maintain proper sealing at the connection point.
• Prevents leaks caused by loose, cracked or corroded clamps.
• Reduces vibration and rattling from unsecured hoses.
• Common symptom: visible leaking, water pooling, or a loose hose connection.

• Disconnect power and shut off water supply before starting any repair.
• Use the correct pliers or screwdriver for the clamp type; avoid damaging the hose.
• Inspect the mating hose and seal; replace any cracked or hardened hoses before reinstalling.
• Do not overtighten—tighten just enough to secure the hose without cutting or deforming it.

The Damper Assembly is an OEM replacement part for LG washing machines. It is a critical component that helps regulate the balance and vibration levels during the spin cycle.

Causes of a bad damper assembly in a washing machine can include excessive wear and tear due to repeated high-speed spinning, damage from excessive vibrations or unbalanced loads, or failure of the internal components responsible for dampening and stabilizing the tub motion.

Symptoms of a bad washing machine damper assembly include:

• Excessive shaking or vibrations during the spin cycle
• Loud thumping or banging noises
• The washer visibly moving or walking across the floor
• Potential leaks due to increased stress on the tub and other components

This OEM LG part is also compatible with Sears/Kenmore models.

The Hinge Pin is an OEM part for LG washing machines. It serves as a pivot point for the washer door, allowing it to open and close smoothly. This component is crucial for maintaining the proper alignment and function of the washer door, ensuring a secure and reliable seal during operation.

Common causes of a bad hinge pin include frequent use leading to wear and tear, physical damage from accidental impacts, or rust and corrosion over time. A compromised hinge pin can result in misalignment of the door, affecting the washing machine's ability to close properly and maintain an effective seal.

Symptoms of a bad hinge pin include:

• Difficulty opening or closing the washer door
• Door not staying securely closed during operation
• Squeaking or grinding noises when the door is moved
• Visible wear or damage to the hinge pin

This OEM LG part is also compatible with Sears/Kenmore models.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.
