Parts for Lg WM3570HWA/00: Drum And Tub Assembly Parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

This outer tub assembly holds wash water and supports the inner drum so the washer can agitate and spin effectively. Replacing a damaged outer tub restores a sealed wash tub and prevents leaks or excessive movement. What it does:

• Houses and seals the wash chamber so water stays inside the washer during fill, wash and spin cycles
• Provides structural support for the inner drum and basket to spin smoothly
• Prevents leaks caused by cracks, corrosion or worn mounting areas
• Helps reduce abnormal noise and vibration related to a damaged tub

• Disconnect power and water supply before starting; drain any remaining water
• This is a large, heavy assembly — two people and basic hand tools are typically needed
• May require removal of the cabinet, inner tub/basket, and related hoses or seals for access
• Inspect and replace associated seals, bearings or mounting hardware as needed

This washer drum lifter (baffle) mounts inside the drum to raise and tumble clothes as the basket turns. Replace a cracked or missing lifter to restore wash action, help protect fabrics, and reduce rattling noises.

• Attaches to the inner drum and lifts garments during rotation for effective tumbling
• Helps distribute loads and improve mechanical cleaning action
• Direct replacement for lifters that are cracked, loose, sharp-edged, or missing
• Typical symptoms: poor tumbling/wash results, thumping or rattling from the drum, clothing snags or tears, lifter wobbling or fallen off

• Disconnect power and turn off water supply before servicing
• Open the door and rotate the drum to access the lifter
• Depending on model, release locking tabs from inside the drum or remove the retaining fastener; align and secure the new lifter
• Ensure the lifter is fully seated and secure; run a short rinse/spin to verify proper operation

This lifter assembly is the plastic baffle inside the drum that lifts and tumbles laundry as the drum turns. Replacing a cracked or missing lifter restores smooth tumbling and helps prevent fabric snags and noisy operation. What it does:

• Lifts and turns items to promote effective tumbling during cycles
• Helps distribute loads more evenly and reduce thumping
• Replaces broken, loose, or missing baffles
• Addresses symptoms like rattling, clothing snagging/tearing, or poor item movement in the drum

• 1 lifter assembly

• Disconnect power before servicing
• Work through the drum opening; remove the old lifter by releasing its locking mechanism
• Align the new lifter's tabs with the drum slots, then slide/lock it securely in place
• Verify it is firmly seated and does not wobble before running a test cycle

The Spider Arm is an OEM part for LG washing machines. As an important component linking internal mechanics, the spider arm connects the basket or tub to other components like the drive motor. It facilitates the spinning motion essential for washing cycles while also enabling water to properly agitate clothing.

Symptoms of a bad spider arm include:

• The tub not spinning or spinning unevenly
• Vibration or noise issues arising from the center of the machine
• Water not draining or agitating clothes as intended
•  premature wear on other connected parts over time

Causes of a bad spider arm can be regular use over several years, damage from excessively heavy loads, or impact from an object inside the tub. Not replacing a faulty spider arm can accelerate damage to other expensive parts.

This LG replacement part is also compatible with Sears/Kenmore models.

This bolt assembly is the shipping bolt used to secure a washing machine's tub and suspension during transport. Replacing a missing or damaged bolt helps protect internal components from vibration and impact when moving the appliance. What it does:

• Locks the tub in place to limit movement during shipping or relocation
• Helps prevent internal damage caused by excessive shaking in transit
• Restores a complete set when one shipping bolt is lost, bent, or stripped
• For transport only—remove all shipping bolts before operating the washer

• 1 bolt assembly

• Unplug the appliance and shut off water before starting
• From the rear, align the bolt with the shipping hole and hand-thread to avoid cross-threading; tighten securely without overtightening
• Install all shipping bolts required by your model (often four) before moving the unit
• After moving, remove all shipping bolts before use and store for future moves

The Bearing Ball is an OEM part for LG washing machines. This component plays a crucial role in the smooth operation of the washer drum, enabling it to rotate quietly and efficiently during the wash and spin cycles.

Causes of a bad bearing ball can include regular wear and tear, exposure to heavy loads, or insufficient lubrication. Over time, these factors can lead to deterioration and reduced performance of the bearing ball, potentially causing the washer drum to spin improperly or not at all.

Symptoms of a bad bearing ball include:

• Loud rumbling or grinding noises during the wash or spin cycles
• The drum not spinning or spinning unevenly
• Increased vibration or movement of the washer
• Leaks from the drum area due to damaged seals

This OEM LG part is also compatible with Sears/Kenmore models.

The Ball Bearing is an OEM part for LG washing machines. It is designed to support the drum's rotation within the washer, ensuring smooth and quiet operation during the wash and spin cycles. This ball bearing helps reduce friction and wear, contributing to the overall efficiency and longevity of the appliance.

Causes of a bad Ball Bearing can include excessive wear due to heavy use, exposure to water or detergent leading to rust or corrosion, or damage from an unbalanced load. Over time, the bearing can degrade, leading to operational issues and increased noise.

Symptoms of a bad Ball Bearing include:

• Loud, unusual noises during the spin cycle
•  The drum not rotating smoothly
• Excessive vibration or shaking
• Leaking from the drum area

This OEM LG part is also compatible with select Sears/Kenmore models.

This factory bolt assembly fastens critical components securely inside your appliance. Replacing a worn, stripped, or missing bolt restores a snug fit, reduces vibration and noise, and helps prevent damage caused by loosening during operation. What it does:

• Secures mating parts to maintain alignment and structural stability
• Helps prevent vibration, rattling, and movement from a loose fastener
• Addresses issues like wobble or intermittent operation in the affected area
• Replaces damaged, corroded, or missing hardware for a reliable hold

• One bolt assembly

• Disconnect power before servicing
• Support the assembly being fastened to avoid strain or misalignment
• Start threads by hand to prevent cross-threading; tighten snugly without overtightening
• Replace companion washers or hardware if worn or damaged; match any threadlocker used on the original

The Rear Tub Gasket is an OEM part for LG washing machines. It provides a watertight seal between the rear tub and the front tub assembly, preventing water leaks during the wash and spin cycles. This gasket ensures that water remains contained within the drum, contributing to the overall efficiency and performance of the washing machine.

You should replace the rear tub gasket if it becomes worn out, cracked, or damaged. Causes of a bad rear tub gasket can include general wear and tear, mold or mildew buildup, and damage from foreign objects during washing.

Symptoms of a bad rear tub gasket include:

• Water leaking from the back of the washing machine
• Visible cracks, tears, or deformation in the gasket
• Mold or mildew buildup around the gasket area
• Unusual noises during the wash cycle indicating a loose or misaligned gasket

This OEM LG part is also compatible with certain models of Kenmore washing machines.

This balance weight is the washer drum counterweight that helps stabilize the tub during spin cycles to reduce vibration and excessive movement. It restores smoother, quieter operation when the drum is unbalanced. What it does:

• Counters the rotating drum to reduce vibration, shaking and banging during spin
• Helps maintain drum alignment for consistent spin performance
• Reduces noise caused by an imbalanced load or worn/loose weight
• Prevents excessive movement that can stress suspension components

• Disconnect power and water supply before starting any repair
• Support the tub/outer cabinet to prevent it from shifting when removing old weight
• Retain and reuse original fasteners only if in good condition; replace damaged hardware

This Screw (drawing) is a factory fastener used to secure appliance panels and components. Replacing a stripped, corroded, or missing screw restores a tight fit, reduces vibration, and helps keep assemblies correctly aligned.

• Secures panels, brackets, and mounting points as specified by the manufacturer
• Replaces screws that are lost, damaged, corroded, or stripped
• Helps address rattling, vibration, or loose-fitting parts caused by missing hardware
• Maintains proper alignment and stability of the assembly

• Disconnect power and, if applicable, shut off gas/water before servicing
• Match the screw to its original location; start threads by hand to avoid cross-threading
• Use the correct driver; tighten snugly without over-torquing into metal or plastic
• Refer to your model's parts diagram to correct location and quantity

A balance weight that helps stabilize the washer tub during spin cycles to reduce vibration and prevent the appliance from rocking. Replaces a worn or broken cabinet weight to restore smoother, quieter operation. What it does:

• Adds mass to the washer cabinet to counteract tub imbalance during spins
• Reduces excessive vibration, shaking, and loud banging noises when spinning
• Helps prevent the washer from walking or shifting on the floor
• Works as the factory replacement for the original cabinet balance assembly

• Disconnect power and, if applicable, water supply before starting any repair
• Empty the drum and remove the required access panels per your model's service manual
• Securely fasten the weight using the original mounting hardware and torque per OEM guidance

This balance weight secures to the appliance frame to add counterweight where needed, helping reduce vibration and stabilize moving parts for quieter, more reliable operation. What it does:

• Adds counterbalance to a drum, door or other moving component to reduce shaking and excessive movement during operation.
• Restores proper weight distribution to prevent off-balance conditions that can trigger vibration or noise.
• Typically fastens to the frame with mounting bolts to transfer and even out dynamic loads.
• A worn, loose or missing balance weight may be linked to loud banging, heavy vibration or uneven operation.

• Disconnect power (and water supply for washers) before starting any repair.
• Remove the appropriate access panels to reach the mounting location; keep fasteners for reassembly.
• Reinstall using the original mounting bolts and follow OEM torque recommendations when available.
• Inspect adjacent suspension, mounts and hardware while servicing.

The Outer Tub Gasket is an OEM replacement part for LG front-load washers. Situated between the front and rear outer tubs, it forms a critical seal preventing water leaks during fills and cycles. Constructed from durable yet flexible rubberized material, this gasket withstands constant compression from tub movements.

Causes for replacement are cracks developing from years of flexing stresses, as well as distortions that compromise sealing integrity. Normal seal compression can also cause gradual wear of sealing material over time.

Symptoms of a faulty front-load outer tub gasket include:

• Puddles or drips of water between or behind the wash tubs
• Dried mineral deposits from leakages around tub connection points

This OEM LG part is also compatible with some Sears/Kenmore.

The Motor Stator Bolt is an OEM part for LG washing machines. This bolt secures the stator to the motor, ensuring the stability and proper functioning of the washing machine's motor assembly.

Causes of a bad motor stator bolt can include wear and tear over time, improper installation, or damage from over-tightening or impact. A compromised bolt can lead to instability in the motor, potentially affecting the washer's performance.

Symptoms of a bad motor stator bolt include:

• Unusual noises during the wash cycle
• Vibrations or shaking of the washer
• The motor not functioning properly or failing to start

This OEM LG part is also compatible with Sears/Kenmore.

The Float Assembly is an OEM part for LG washing machines. This part monitors and controls the water level within the appliance. It's a safety feature that prevents water overflow and potential flooding, contributing to the efficient operation of the washing machine by maintaining the correct water level for each cycle.

Causes of a bad Float Assembly can vary from simple blockages that prevent the float from moving freely to electrical faults within the switch mechanism.

Symptoms of a bad Float Assembly include:

• Water overflowing from the washing machine
• Inadequate water levels that affect the washing cycle's effectiveness
• The washing machine failing to start the fill cycle due to a malfunctioning float switch

This OEM LG part is also compatible with some Kenmore models.

The Dispenser Hose is an OEM part for LG washing machines. It connects the detergent dispenser to the washer tub, allowing detergent and other cleaning agents to be delivered effectively during the wash cycle.

Causes of a bad dispenser hose can include regular wear and tear, damage from harsh detergents, or physical damage due to kinks, pinches, or impact. Over time, the hose can become brittle, cracked, or clogged, affecting its ability to function properly.

Symptoms of a bad dispenser hose include:

• Leaks or drips from the hose area
• Detergent not dispensing correctly or at all
• Water pooling around the washer
• Visible cracks or splits in the hose

This OEM LG part is also compatible with Sears/Kenmore models.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

The Vent Hose is an OEM part for LG washing machines. This hose is essential for ensuring proper ventilation within the washer, allowing air to circulate and preventing the buildup of moisture and mildew. It helps maintain the efficiency of the washing machine by facilitating the expulsion of air and excess water vapor during operation.

Causes of a bad washer vent hose can include wear and tear over time, blockages from lint or debris, or damage due to bending or pinching.

Symptoms of a bad vent hose include:

• Excessive moisture or condensation inside the washer
• Musty odors from the washing machine
• Visible cracks or holes in the hose
• Poor ventilation leading to inefficient washing cycles

This OEM LG part is also compatible with Sears/Kenmore.

Includes sensor probe

Includes sensor probe

The LG Stator Assembly is an OEM component for LG washing machines. It is the central electromechanical part that transforms incoming AC power into the rotational force needed to turn the washer basket. Magnetic fields generated by the stator coil spin the internal drum during wash and rinse cycles.

Symptoms of a bad stator assembly include:

• The basket not spinning or agitating at all
• Buzzing noises coming from inside the washer cabinet
• Tripped circuit breakers or blown fuses indicating power issues

Causes of failure relate to excessive heat built up over many years that damages insulation or coils within the stator. Wiring connections may also degrade. Without sufficient power transmission from the stator, critical cleaning functions do not occur.

This LG replacement part is also compatible with Kenmore models using LG parts.

The Connector Hose is an OEM part for LG front-loading washing machines. It is a flexible vinyl tube that connects the water supply line to the individual water valves and nozzles inside the washer. As water flows through this hose during wash cycles, it must withstand pressure and thermal expansion/contraction.

Causes of a bad connector hose can include cracks, splits, or leaks developing from repeated bending and flexing over thousands of wash cycles. Mineral buildup or scale deposits inside the hose can also restrict water flow.

Symptoms of a bad connector hose include:

• Water supply issues such as low pressure, reduced flow, or leaks
• Mineral deposits causing clogged or dripping nozzles
• Discolored or brittle hose material

Replacing the hose with a new OEM LG part restores proper water connections for improved washing performance. It is also compatible with Sears/Kenmore front-load washer models.

This is the direct-drive rotor for the dishwasher wash motor. It pairs with the stator to spin the impeller and circulate wash water through the spray arms, helping restore proper spray pressure and quieter operation when the original rotor is worn.

• Couples with the stator to drive the circulation pump impeller
• Moves wash water through the spray arms for consistent cleaning performance
• Common failure signs: little or no spray, poor cleaning, loud humming or grinding from the pump area, or intermittent wash action
• Physical damage or weakened magnets can prevent proper rotation

• Disconnect power and water supply and pull the unit forward for access
• Remove the toe-kick and drain remaining water at the sump
• Remove the pump cover and center fastener, then pull the old rotor straight off
• Seat the new rotor fully, reassemble, and run a test cycle to check operation and leaks

The Connector Hose is an OEM part for LG front-loading washing machines. It is a flexible vinyl tube that connects the water supply line to the individual water valves and nozzles inside the washer. As water flows through this hose during wash cycles, it must withstand pressure and thermal expansion/contraction.

Causes of a bad connector hose can include cracks, splits, or leaks developing from repeated bending and flexing over thousands of wash cycles. Mineral buildup or scale deposits inside the hose can also restrict water flow.

Symptoms of a bad connector hose include:

• Water supply issues such as low pressure, reduced flow, or leaks
• Mineral deposits causing clogged or dripping nozzles
• Discolored or brittle hose material

Replacing the hose with a new OEM LG part restores proper water connections for improved washing performance. It is also compatible with Sears/Kenmore front-load washer models.

This hose clamp secures a rubber hose connection to prevent leaks where the hose meets its fitting. A tight, uniform seal helps maintain proper water flow and keeps the appliance operating reliably.

• Provides a tight, 360-degree seal around the hose barb/fitting
• Helps correct issues like water leaks at the hose connection point
• Maintains correct hose attachment during operation and vibration
• Step-less ear design distributes clamping force evenly

• Unplug power and shut off water supply before servicing
• Note clamp orientation and hose routing before removal
• Use appropriate ear-clamp pincers or pliers to compress the clamp evenly
• Check the hose and fitting for wear; replace if cracked or deformed

This tub clamp secures the washer tub assembly or related hoses to keep components aligned and reduce movement during operation. It helps restore proper fitment so the tub stays stable and functions quietly. What it does:

• Holds the tub or tub-related components in place to prevent shifting during cycles
• Helps reduce vibration and noise caused by loose tub mounting
• Maintains correct alignment of hoses and seals to reduce leak risk
• Used when a worn or broken clamp allows excessive tub movement

• One tub clamp

• Turn off power and water supply before beginning any repair
• Inspect surrounding components (hose, seal, mounting points) and replace if damaged
• Use common hand tools; secure clamp evenly to avoid twisting the tub or hoses

A replacement hose clamp that secures a flexible hose to its fitting to help prevent leaks and disconnections. Restores a tight, reliable seal so hoses stay seated during normal use. What it does:

• Holds a rubber or plastic hose firmly to a pump, valve or connection to prevent leaks.
• Helps stop hose pull-off that can cause water leaks or appliance interruptions.
• Commonly replaced when clamps are corroded, bent, cracked or missing.
• Works as a low-cost repair to restore a secure hose connection without replacing the hose assembly.

• Disconnect power to the appliance and shut off the water supply before servicing.
• Use the correct tool (slip-joint pliers for spring-style clamps or a screwdriver for screw-type clamps) and avoid pinching the hose.
• Inspect the hose and fitting for damage; replace the hose if it's cracked or excessively worn.
• After installing, restore power/water and run a short test cycle or check for leaks.

The Door Boot Gasket is an OEM part for LG washing machines. It is seated around the perimeter of the washer door opening and forms a watertight seal during wash cycles.

Symptoms of a bad door boot gasket include:

• Water or moisture leaking from the door into the surrounding area
• Puddles or drips present after operating the washer
• The gasket no longer forms a flush, wrinkle-free seal around the opening

Causes of a faulty door boot gasket can be repetitive washing loads putting pressure on the seal, harsh detergents deteriorating the material over time, or physical damage weakening the integrity.

Replacing your LG OEM door boot gasket will restore a tight closure, preventing water intrusion that could lead to further issues. The new gasket fits precisely into the channel for a durable, long-lasting seal. This replacement part is also compatible with Sears/Kenmore models.

The Gasket is an OEM part for LG washing machines. This part ensures a tight and leak-proof seal between the door and the machine's body. This part prevents water from leaking out during the wash cycle, thereby safeguarding the surrounding area from water damage and maintaining the efficiency of the wash cycle.

Causes of gasket failure include the natural degradation of material over time, accumulation of soap scum and debris, and damage from loading and unloading laundry.

Symptoms of a bad Gasket include:

• Visible cracks, holes, or signs of wear in the gasket
• Water leaking from the front door area of the washing machine
• Mold or mildew buildup on the gasket, which can also cause odors

This OEM LG part is also compatible with some Kenmore models.

The Gasket is an OEM part for LG washing machines, designed to create a watertight seal between the door and the machine's body. This part prevents water from leaking out during the washing cycle. Over time, however, the gasket can wear down, lose its elasticity, or become damaged, leading to leaks and potential water damage. Causes of a bad gasket can range from natural wear and tear over time.

Symptoms of a bad Gasket include:

• Water leaking from the door
• Visible signs of wear, such as cracks or holes
• Mold or mildew on the gasket
• Difficulty closing the door

This OEM LG part can also be used on Kenmore/Sears appliances.

The Nozzle Connector is an OEM part for LG washers. This connector piece attaches to the water supply lines and direct tub fill nozzle, directing water into the washer tub during fill cycles. It allows water to be distributed evenly around the tub perimeter during fills to optimize cleaning performance.

Causes of a bad connector can include cracks, leaks, or blockages from mineral buildup that disrupt water flow.

Symptoms of a bad connector include:

• Uneven or inadequate water levels in the tub during fills
• Slow or inefficient fills requiring multiple attempt
• Water leaks from the connector area
• Mineral buildup visibly clogging the connector

This OEM LG part is also compatible with some Kenmore models.

A molded water guide that routes dispenser water inside the refrigerator to the dispenser/ice area, helping direct flow and reduce splashing. Fits the factory mounting points for a clean, secure path for water. What it does

• Channels water from the inlet tubing toward the dispenser/ice assembly to prevent misdirected flow.
• Helps keep water from pooling or dripping inside the cabinet or on internal components.
• Common replacement when you see water on shelves, puddling near the dispenser, or reduced or misdirected dispenser flow.
• Preserves proper alignment of the dispenser plumbing to prevent kinks or strain on tubing.

• One water guide (single molded channel) as shown.

• Turn off the refrigerator and shut off the water supply before starting; disconnect power for safety.
• Remove interior panels or shelves as needed to access mounting points; keep fasteners for reassembly.
• Inspect adjoining tubing and seals for damage and replace any worn components to ensure a leak-free fit.
• After installation, restore power and water, then check carefully for leaks during an initial test dispense.

The Tub to Pump Hose is an OEM replacement part for LG top-load washing machines. This hose safely transports water between the wash tub and drain pump. The hose measures 13 inches in length.

Causes of failure relate to constant flexing under water pressure strains that accumulate over years of usage. Excess minerals in hard water areas promote accelerated breakdown of flexible PVC material.

Symptoms of a cracked or leaking tub to pump hose include:

• Water not draining or taking an abnormally long time
• Water continually accumulating inside the machine cabinet
• Error codes related to drainage issues displayed
• Puddles forming near or under the back of the washer

This genuine LG hose is also compatible with select Sears/Kenmore units as well.

The Air Chamber is an OEM part for LG washing machines. This part connects to the pressure switch and ensures the washer machine fills with the correct amount of water for the selected cycle.

Causes of a bad  Air Chamber can include clogging due to detergent residue or debris, cracks or perforations that lead to air leaks, and aging of the material, which might compromise its integrity and function.

Symptoms of a faulty Air Chamber include:

• Inaccurate water level readings leading to overfilling or insufficient water during cycles
• Unusual noises during the fill cycle, indicating air escaping
• The washing machine failing to start the wash cycle due to improper water level detection
• Error codes displayed on the machine that relate to water level issues

This OEM LG part is also compatible with some Kenmore models.

This inlet hose routes household water into the appliance's fill system, providing a secure, watertight connection. Replacing a worn, cracked, or leaking hose restores proper fill and helps prevent leaks and cycle interruptions.

• Directs incoming water from the supply connection to the appliance's inlet/fill assembly
• Maintains a sealed path to prevent drips and leaks
• Replace if the hose is cracked, swollen, kinked, or fittings are corroded
• Typical symptoms include leaks behind/under the unit, slow or no fill, or a water supply error message

• Disconnect power and shut off the water supply before servicing
• Place a towel or pan to catch residual water and relieve line pressure
• Note routing and fitting orientation; transfer any seals/clips from the original if required
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening, then restore water and check for leaks

This connector hose replaces the appliance's water connection to restore secure water flow and reduce the risk of leaks or interrupted dispenser/ice-maker operation. It's a direct replacement for a damaged or leaking supply connector. What it does:

• Connects the household water supply to the appliance's internal water valve or dispenser.
• Restores reliable water flow when a cracked, split, or collapsed hose prevents proper delivery.
• Reduces water leakage caused by worn or damaged connector ends and seals.
• Commonly needed when you see visible leaks, no water to the dispenser/ice maker, or a loose/broken hose connection.

• Turn off water supply and unplug the appliance before replacing the hose to avoid electric shock or water damage.
• Use proper clamps and fittings; make sure connections are seated and tightened just enough to stop leaks—do not overtighten.
• After installation, restore power and water, then check all connections carefully for leaks. Replace immediately if the hose or fittings show signs of damage.

This clamp assembly secures a hose or tubing connection to maintain a watertight seal and reduce vibration. Replacing a worn or damaged clamp helps stop leaks and prevents hoses from slipping loose during operation. What it does:

• Holds a hose or tube firmly in place to maintain proper sealing at the connection point.
• Prevents leaks caused by loose, cracked or corroded clamps.
• Reduces vibration and rattling from unsecured hoses.
• Common symptom: visible leaking, water pooling, or a loose hose connection.

• Disconnect power and shut off water supply before starting any repair.
• Use the correct pliers or screwdriver for the clamp type; avoid damaging the hose.
• Inspect the mating hose and seal; replace any cracked or hardened hoses before reinstalling.
• Do not overtighten—tighten just enough to secure the hose without cutting or deforming it.

The Hinge Pin is an OEM part for LG washing machines. It serves as a pivot point for the washer door, allowing it to open and close smoothly. This component is crucial for maintaining the proper alignment and function of the washer door, ensuring a secure and reliable seal during operation.

Common causes of a bad hinge pin include frequent use leading to wear and tear, physical damage from accidental impacts, or rust and corrosion over time. A compromised hinge pin can result in misalignment of the door, affecting the washing machine's ability to close properly and maintain an effective seal.

Symptoms of a bad hinge pin include:

• Difficulty opening or closing the washer door
• Door not staying securely closed during operation
• Squeaking or grinding noises when the door is moved
• Visible wear or damage to the hinge pin

This OEM LG part is also compatible with Sears/Kenmore models.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.
