Parts for Maytag MGT3800TW2: 03 - Dryer Cabinet And Motor Parts

This motor mount clamp secures the dishwasher's pump/motor assembly to its housing, keeping the motor stable and the seal tight. Replace a damaged clamp to help prevent leaks and reduce vibration or rattling noise.

• Secures the pump/motor assembly at the mount to prevent movement
• Helps maintain a watertight seal at the motor connection
• A failed clamp can lead to leaking from the base area
• May cause excessive vibration or rattling during operation

• Disconnect power and turn off the water supply before servicing
• Access the pump/motor from beneath; support the assembly to relieve tension
• Note clamp orientation; ensure the existing seal is properly seated and tighten the new clamp evenly
• After reassembly, run a short cycle and check for leaks

Dryer motor used in washer/dryer stack units.

The Broken Belt Switch Kit is an OEM replacement part for Whirlpool dryers. It is an assembly that includes a microswitch and bracket installed to monitor the dryer drum belt status. The broken belt switch plays an important safety role by automatically stopping the dryer if it detects the drum belt breaking or slipping off the motor pulley during a cycle. The kit includes a switch, actuator lever, screws, and wire terminals.

Causes of a bad broken belt switch can include wear and tear over time, electrical malfunctions, or physical damage from a broken belt or other internal issues. Ensuring the switch is functioning correctly is crucial for the safe and efficient operation of the dryer.

Symptoms of a broken or failing switch include:

• The dryer failing to shut off if the belt breaks during operation
• Inability to diagnose belt issues through error code displays
• Intermittent stopping or variance in belt tension detection

This genuine Whirlpool switch replacement is also compatible with Kenmore, Maytag, Jenn-Air, and KitchenAid dryer models.

Specs: 10-16 x 1/2 inch.

This is a 10-16 x 1/2 inch appliance screw used to secure panels and components on compatible Whirlpool laundry and kitchen appliances. It restores a secure fit when a fastener is missing or stripped. What it does

• Fastens trim, panels, brackets or small components to the appliance chassis
• Replaces a lost or damaged factory screw to stop rattling or loose parts
• Matches OEM thread and length for proper engagement and holding strength
• Helps maintain alignment and safe operation of the attached part

• Use the correct screwdriver or nutdriver to avoid stripping the head
• Tighten until snug—do not overtighten to prevent damage to threads or sheet metal
• Disconnect power and follow the appliance manufacturer's safety instructions before servicing

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This right-side replacement panel restores the exterior finish and protection on your appliance. It matches the original fit and appearance to help maintain the cabinet's look and shield internal components. What it does

• Replaces a cracked, dented or scratched right-side cabinet panel
• Restores the appliance's outer finish and prevents exposure of internal parts
• Helps maintain proper alignment of the cabinet edges and trim
• Useful for cosmetic repairs after bumps or wear

• Disconnect power (and water if applicable) before starting any repair
• Basic hand tools are typically required; retain factory fasteners when possible
• Handle carefully to avoid scratching the finish during installation

10 - 16 x 1/2

This replacement lid stop bumper cushions and stabilizes the washer lid, helping prevent hard slams and reducing wear on the lid and cabinet. Restores smoother, quieter lid operation on compatible top-load washers. What it does:

• Acts as a soft stop that cushions the lid when closing to reduce noise and impact.
• Keeps the lid aligned and prevents metal-on-metal contact that can cause scratches or damage.
• Helps the lid sit flush and avoid rattling during wash cycles.
• Suitable as a direct replacement for worn, cracked, or missing lid bumpers.

• One white lid stop bumper as shown.

• Disconnect power before inspecting or servicing the washer.
• Typically installs by pressing into the mounting hole on the lid or cabinet;
• Replace when the bumper is torn, compressed, or missing to restore proper cushioning.

This front panel clip secures the appliance's front/console panel to the cabinet, keeping the panel aligned and preventing vibration or rattling. It's a small but essential fastener for a tight, stable fit. What it does:

• Holds the front or control panel in position on the appliance cabinet
• Prevents panel movement, rattling, or gaps that can affect alignment
• Helps maintain a flush fit between the panel and surrounding trim
• Commonly needed when clips are cracked, broken, or missing

• Disconnect power (and gas if applicable) before beginning any service
• Access usually requires removal of trim or control console; use appropriate screwdrivers
• Replace any additional damaged clips to ensure even panel support

This U-type nut clips over a sheet-metal edge to create a durable threaded anchor for a screw. It helps secure panels, trim, and brackets so fasteners hold tight and components stay aligned and rattle-free. What it does:

• Clips onto thin sheet metal to provide captive threads where a standard nut cannot be used
• Holds screws securely to fasten panels, trim pieces, or mounting brackets
• Addresses issues like loose panels, missing/broken clips, or screws that will not tighten
• Helps reduce vibration and rattling from unsecured components

• 1 U-type nut

• Disconnect power and shut off gas/water before servicing
• Position the U-nut over the panel edge with the threaded side aligned to the hole
• Start the screw by hand to avoid cross-threading; tighten snugly without overtightening
• Replace any damaged or corroded hardware to ensure a secure hold

The Drum Support Wheel Retainer is an OEM part for Whirlpool dryers. This part secures the drum support wheels in place, ensuring that the dryer drum rotates smoothly and quietly during operation. The retainer is designed to fit precisely, preventing the support wheels from loosening or wobbling, which can lead to inefficient drying and increased wear on other components.

Over time, retainers can wear out or become damaged, potentially leading to a loose drum support wheel. This can cause the dryer to operate noisily, vibrate excessively, or even damage the drum itself if not addressed promptly.

Symptoms of a bad Drum Support Wheel Retainer include:

• Unusual noises, such as squeaking or thumping, coming from the dryer
• Excessive vibration during operation
• The dryer drum may feel unstable or wobble when turned by hand

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This replacement washer is a small hardware component used in appliance assemblies to provide a stable bearing surface and proper spacing. Replacing a worn or missing washer helps maintain alignment, reduce vibration, and protect mating parts from damage.

• Distributes load under a nut, bolt, pin, or shaft to protect mating surfaces
• Maintains correct spacing and alignment within stacked components
• Helps reduce friction, vibration, and noise in moving assemblies
• Worn or missing washers can contribute to looseness, wobble, rattling, or premature wear

• Disconnect power and shut off gas/water before servicing
• Note the original order and orientation of parts during disassembly
• Inspect fasteners, shafts, and bushings; replace any that show wear or damage
• Tighten fasteners securely per the service manual; do not overtighten

The Drive Belt is an OEM replacement part for Whirlpool dryers. This essential component is responsible for transferring power from the dryer's motor to the drum, allowing it to spin and tumble the clothes during the drying cycle.

Symptoms of needing to replace the drive belt include:

• The dryer drum not spinning or rotating
• Loud squeaking or grinding noises during the drying cycle
• Excessive vibration or shaking from the dryer
• Clothes taking longer to dry or remaining damp

Causes of a faulty drive belt can include normal wear and tear over time, exposure to excessive heat or lint buildup, or physical damage due to impact or mishandling.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore dryer models.

Dryer motor used in washer/dryer stack units.

This idler pulley assembly keeps the drive belt properly tensioned and aligned so your appliance runs smoothly and quietly. Replacing a worn or seized idler restores reliable belt drive and helps prevent slippage, noise, and no-drive issues.

• Maintains spring-loaded tension on the drive belt
• Spins freely to reduce friction and belt wear
• Helps route and align the belt between the motor and drum/basket
• Typical symptoms of a failing idler: squealing/chirping, belt fraying or coming off, intermittent or no tumble/spin, burning rubber smell

• Disconnect power; for gas units, also shut off the gas supply.
• Relieve belt tension, swap the assembly, and route the belt per your unit's diagram.
• Rotate the drum/basket by hand to check alignment.
• Wear cut-resistant gloves and use caution around sharp edges and spring tension.

The Idler Arm Spring is an OEM part for Whirlpool dryers, maintains tension in the dryer's belt system. This spring is crucial for the proper operation of the dryer, as it helps to keep the belt tight around the drum and motor pulley, enabling the drum to rotate smoothly during cycles.

Causes of a bad Idler Arm Spring can include stretching or weakening over time due to constant tension, or breakage from wear and tear.

Symptoms of a bad Idler Arm Spring include:

• Unusual noises, such as squeaking or squealing
• The dryer drum may not rotate smoothly or may stop turning altogether
• Clothes take longer to dry, or you may notice uneven drying
• The dryer might not start if the belt is disengaged due to insufficient tension.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Specs: 10-16 x 1/2 inch.

This is a replacement power cord that restores electrical connection between your appliance and the household outlet, letting the appliance receive mains power safely. It replaces a damaged or worn cord to help restore normal operation. What it does:

• Carries mains voltage from the wall outlet to the appliance so it can power up and operate
• Replaces frayed, melted, or broken cords that can cause intermittent power or no power at all
• Helps eliminate arcing or loose connection symptoms that may trip breakers or cause burning smells
• Restores a secure, strain-relieved connection when the original cord or terminal is damaged

• One replacement power cord

• Always disconnect power at the breaker or unplug the appliance before replacing the cord
• Route the cord and secure the strain relief or clamp per the appliance's wiring access panel

The lid switch lever connects the washer's lid hinge to the lid switch, signaling when the lid is closed so the cycle can run. A damaged lever can prevent the safety interlock from closing, leading to no-start or spin issues. What it does:

• Transfers lid movement at the hinge to the lid switch actuator
• A closed lid so the washer can operate
• Common symptoms of a failed lever: washer won't start; won't spin; cycle pauses because the lid-closed signal isn't detected

• 1 lid switch lever

• Disconnect power before servicing
• Lift or open the top to access the hinge/switch area; locate the lever near the lid switch
• Remove the old lever and install the new one in the same orientation; free movement
• Close the lid by hand and the switch clicks before reassembly and testing

Size: 6 - 20 x 1 1/16 inch.

The Idler Arm Bolt is an OEM part for Whirlpool dryers. It secures the idler pulley, which maintains the proper tension on the dryer drum belt.

Causes of a bad idler arm bolt can include wear and tear from prolonged use, vibration and movement within the dryer, or improper installation.

Symptoms of a bad idler arm bolt include:

• The dryer drum not rotating properly
• Unusual noises such as squeaking or grinding
• The dryer belt slipping or coming off the pulley
• The dryer not drying clothes effectively

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Idler Pulley is an OEM replacement part for Whirlpool dryers. This essential component plays a crucial role in the drum drive system, helping to guide and maintain proper tension on the dryer belt.

Causes of a faulty idler pulley in a dryer can include normal wear and tear over time, improper belt tensioning leading to bearing failure, or physical damage from impact or debris buildup.

Symptoms of needing to replace the idler pulley include:

• Squeaking or grinding noises from the driveability area
• The dryer drum not spinning or rotating properly
• Excessive vibration or shaking during the dryer cycle

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore dryer models.

This screw grommet anchors a screw in thin appliance panels so trim, covers, or consoles stay tight. It provides a snug, vibration-damping fit where a standard screw could loosen or strip over time.

• Creates a captive insert so a screw can securely fasten to sheet metal or plastic panels
• Replaces a worn, cracked, or missing grommet to restore proper screw retention
• Helps reduce panel rattles and movement from vibration
• Typical signs of failure: screw won't tighten, panel or trim feels loose, grommet falls out

• Disconnect power and shut off gas/water as applicable before servicing
• Remove the screw and lift out the old grommet; clear debris from the opening
• Press the new grommet straight into the hole until fully seated and flush
• Reinstall the screw and tighten gently to avoid deforming the grommet
