Parts for Kenmore 796.31433710 (79631433710, 796 31433710): Other Parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

This tapping screw fastens appliance panels and components for a secure, lasting hold. Replace stripped, rusted, or missing hardware to restore proper fit, reduce vibration and rattling, and keep brackets, covers, and trim tightly in place.

• Fastens metal or plastic panels, trim, or brackets to the appliance cabinet/frame
• Cuts its own threads in pre-drilled holes for a tight, reliable fit
• Helps maintain alignment and reduce movement that can cause noise
• Replace when the original screw is missing, stripped, corroded, or will not tighten

• Disconnect power and shut off water/gas before servicing
• Match the screw's position and length to the original hardware
• Start by hand to avoid cross-threading; tighten snugly—do not overtighten
• Reuse any washers or spacers from the original assembly if present

The Pulsator Cap is an OEM part for LG washing machines. It is designed to secure the pulsator (or agitator) in place, ensuring proper movement of the wash plate during the wash cycle. This component helps in the effective distribution of water and detergent, promoting thorough cleaning of clothes.

You should replace this pulsator cap if it becomes damaged, lost, or worn out. Causes of a bad pulsator cap can include regular wear and tear, exposure to heavy loads, or damage from improper handling. A compromised cap can lead to inefficient washing and potential damage to the pulsator.

Symptoms of a bad Pulsator Cap include:

• The pulsator becoming loose or dislodged
• Unusual noises during the wash cycle
• Clothes not being cleaned properly
• The washer experiencing imbalance issues

This OEM LG part is also compatible with Sears/Kenmore models.

The Customized Screw is an OEM part for securing the wash plate in LG washing machines. This screw maintains the wash plate's position and stability during the washer's operation. The Customized Screw ensures the wash plate performs efficiently, contributing to the effectiveness of the washing process by enabling proper agitation and circulation of clothes.

Causes of a bad Customized Screw can include wear and tear over time, especially from the constant motion and stress during the wash cycles.

Symptoms of a bad Customized Screw include:

• The wash plate becoming loose or detached
• Ineffective washing due to improper motion of the wash plate
• Unusual noises during the wash cycle indicating a loose component

This OEM LG part is also compatible with some Kenmore models.

This damper controls airflow between compartments to help maintain consistent temperatures and efficient cooling. It replaces a worn or failed damper to restore proper air distribution and reduce temperature swings. What it does:

• Regulates airflow between freezer and fresh-food compartments for balanced temperatures
• Can cause uneven cooling or warm fresh-food compartment when faulty
• May click, stick, or fail to open/close if broken or obstructed
• Works with the refrigerator's control system to adjust airflow based on settings

• Disconnect power before beginning any service to avoid electric shock
• Handle the damper and housing carefully to avoid damage to plastic fins or linkage
• Note orientation and actuator connection before removal to ensure correct reassembly
• Test operation after reinstalling by restoring power and cycling temperature controls

Replace a damaged or stripped leveling foot with this leg assembly. It supports the appliance and adjusts for height so you can level it on uneven floors, restoring stability and helping reduce vibration, noise, and movement. What it does:

• Provides adjustable height to properly level the appliance
• Supports the cabinet/frame to keep all corners in firm contact with the floor
• Helps reduce rocking, walking, vibration, and rattling noises
• Fixes: appliance wobbles or is unstable; foot is cracked/missing; threads are stripped; cannot be leveled

• One leg assembly

• Disconnect power and, if applicable, turn off the water supply before servicing
• Carefully tilt or raise the appliance; protect the floor from scratches
• Unscrew the old leg; thread the new leg in by hand and adjust height to level
• Ensure all feet contact the floor firmly and the unit is stable before use

This cap screw is a factory fastener that secures appliance components. Replace a stripped, corroded, or missing screw to restore a tight, rattle-free fit and proper alignment of brackets, panels, and internal assemblies.

• Secures panels, brackets, or assemblies to the chassis or housing
• Maintains alignment to reduce vibration and rattling noise
• Replaces hardware with worn threads, corrosion, or a damaged head
• Common signs: loose/moving parts, buzzing or rattle, and inability to tighten

• Disconnect power (and water, if applicable) before service
• Match length and head style to the original; replace one fastener at a time to preserve alignment
• Start threads by hand to avoid cross-threading; use the correct driver; tighten snugly—do not overtighten
• If the receiving threads are stripped, repair or replace the mating component before final assembly

This hardware washer sits beneath a screw or nut to spread load and help keep fasteners tight inside your appliance. Replacing a bent or missing washer restores a secure fit and can reduce vibration-related noise. What it does:

• Distributes clamping force to protect mounting surfaces
• Helps resist loosening from vibration and movement
• Restores proper alignment when a washer is damaged or missing
• Common symptoms: loose or wobbling parts, rattling noises, screws backing out

• 1 washer

• Disconnect power; if working on a washer, also turn off water supply
• Note the original hardware stack order and take photos for reference
• Place the washer between the fastener head or nut and the part being secured
• Tighten to manufacturer guidance; avoid overtightening to prevent damage

This genuine hardware washer installs at the specific joint shown in your model's parts diagram. It spreads clamp force and keeps the connection aligned and secure to support smooth operation of the related component. What it does:

• Distributes fastener load and protects mating surfaces from damage
• Maintains proper spacing and alignment within the assembly
• Helps resist loosening from vibration over time
• Clues it may be needed or worn: loose/rattling parts, unusual vibration or noise, or visible wear at the fastener location; on some models, seepage at that joint

• 1 washer

• Disconnect power and turn off water supply before servicing
• Support the assembly, remove the fastener, and install the washer in the same orientation
• Tighten the fastener snugly without overtightening; replace any damaged bolts, nuts, or seals

The Drain Pump Assembly is an OEM replacement part for LG washing machines. As an important part of the washer drain system, it drives the pumping action removing water from the tub at the end of each cycle.

Causes of drain pump failure include normal wear from continuous operation over time, foreign debris potentially clogging the impeller cavity, or mineral/scale buildup inhibiting pump function.

Symptoms of a faulty drain pump can include:

• Washer fails to fully drain water at the end of cycles
• Excess water remains in the tub requiring manual emptying
• Abnormal grinding/knocking noises emit from below the tub

This OEM LG part is also compatible with some Sears/Kenmore model washing machines.

Top cover replaces a damaged or worn cabinet top to restore the appliance's appearance and protect internal components from dust and moisture. It's a direct-fit exterior panel used where the cabinet top is cracked, dented, or warped. What it does:

• Covers and protects internal components from debris, moisture, and everyday wear
• Restores the appliance's cosmetic appearance by replacing a scratched or dented top
• Eliminates rattling or movement caused by a loose or damaged top panel
• Provides a secure surface for control panels, hinges, and trim to mount to

• Disconnect power before servicing; work on a cool, dry surface
• Remove any trim, control panel, or hinges that block access per your model's service instructions
• Lift off the old top and align the replacement; secure with the original fasteners

The Drain Hose is an OEM part for LG washing machines. This hose is essential for directing used water out of the washing machine and into the household drain system, ensuring efficient water removal after each wash cycle. The hose measures 67.5 inches in length.

Causes of a bad drain hose can include wear and tear from repeated use, blockages from debris or lint, or physical damage such as cracks or splits. A compromised drain hose can lead to water leakage, improper drainage, or even flooding.

Symptoms of a bad Drain Hose include:

• Water not draining properly from the washing machine
• Leaks or puddles of water around the washing machine
• Visible cracks or splits in the hose
• Unusual sounds during the draining process

This OEM LG part is also compatible with Sears/Kenmore models.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

This is a factory replacement parts assembly designed to restore proper fit and function of a specific component group in your appliance. Use it to replace a worn, damaged, or missing original assembly and maintain reliable operation. What it does:

• Provides a complete, preassembled component group specified by the manufacturer
• Restores proper alignment, support, and operation of the associated parts
• Helps resolve issues like looseness, rattling, misalignment, or intermittent function
• Direct-fit replacement engineered to match the original design

• One parts assembly

• Disconnect power (and shut off water or gas, if applicable) before servicing
• Refer to your model's service documentation for the exact location and procedure
• Handle sharp edges and components carefully; wear cut-resistant gloves
• Verify correct operation before final reassembly

This switch assembly is the microwave's door interlock module. It mounts to the latch board and contains the switches that confirm the door is closed, restoring consistent start/stop operation when worn or sticking switches cause intermittent "door" errors.

• Houses and positions the interlock micro-switches on the latch board
• Signals the control that the door is securely closed so the unit can run
• Common fixes for: won't start, stops when the door is jostled, "door" error messages, or runs but doesn't heat
• Helps correct intermittent operation caused by fatigued or misaligned switches

• Disconnect power before servicing; microwaves retain dangerous high voltage
• Remove the upper grille and control panel to access the latch area per your model
• Note wire locations and switch orientation; move connectors one at a time to the new assembly
• After installation, verify door latching and test operation before reassembly

The Tub to Pump Hose Assembly is an OEM part for LG washing machines. This hose connects the tub to the drain pump, allowing water to be efficiently drained from the washing machine during the spin and drain cycles.

Over time, the hose can become clogged, develop cracks, or experience wear due to constant water flow and agitation. Damage can also occur from accidental mishandling or impact, leading to leaks or improper drainage.

Symptoms of a bad Tub to Pump Hose Assembly include:

• Water leaking from the washing machine
• Slow or incomplete drainage
• Error codes related to drainage issues
• Excess water remaining in the tub after the cycle

This OEM LG part is also compatible with Sears/Kenmore.

The Softener Cap is an OEM part for LG washing machines. It serves as the lid and housing for the internal water softener that prevents mineral deposits from building up. The softener cap funnels water to and from the softener compartment during various stages of the wash cycle.

Causes of a faulty softener cap can include cracked or degraded seals over extended usage, impact damage distorting fit, or harsh cleaners affecting plastics over time.

Symptoms of a bad softener cap include:

• Water leaks from around the softener area
• The cap not closing or sealing properly
• Mineral buildup occurring prematurely
• The softener not functioning as intended

This genuine LG replacement is compatible with Sears/Kenmore machines.

This softener cap seals and directs fabric softener from the dispenser so it dispenses correctly during the wash cycle. Replacing a worn or cracked cap helps prevent leaks and ensures the softener flows into the drum at the right time. What it does:

• Seals the fabric softener reservoir to prevent drips and leaks during filling and storage
• Guides softener into the rinse cycle so the appliance dispenses at the proper time
• Replaces cracked, warped, or missing caps that cause leaking or improper dispensing
• Restores a secure fit between the dispenser assembly and the softener reservoir

• One softener cap

• Unplug the appliance or disconnect power before servicing
• Remove the dispenser drawer or housing to access the cap
• Press or snap the cap into place until fully seated; do not force or overtighten
• Inspect dispenser for residue or damage and clean before reinstalling

This replacement door hinge restores smooth, aligned opening and closing. Replacing a worn or bent hinge helps the door sit squarely and seal or latch properly, preventing rubbing, binding, and premature wear on adjoining parts. What it does:

• Supports and pivots the door for smooth operation
• Maintains door alignment for proper latch/seal engagement
• Replaces bent, cracked, or loose hinges that affect door movement
• Common symptoms include door sagging, rubbing/binding, difficulty closing, or visible hinge damage

• One door hinge

• Disconnect power before servicing; remove door contents to reduce weight
• Support the door while removing hinge fasteners to prevent strain on the new part
• Transfer and reuse original hardware as required; tighten screws to manufacturer-recommended snugness
• Verify door alignment and operation after installation and adjust as needed

A friction damper assembly that cushions and controls the movement of a door or panel to reduce slamming and improve closing action. Replaces a worn damper to restore smoother, controlled motion. What it does:

• Cushions and slows door/panel movement to prevent abrupt closing or opening
• Helps the door stay in position instead of snapping shut or falling open
• Reduces noise and wear from sudden impacts or vibration
• Eliminates symptoms like noisy operation, uncontrolled closing, or a loose-feeling hinge

• Disconnect power and remove any panels or trim to access the damper
• Retain fasteners and note orientation; install the new damper in the same position
• Reinstall panels and test the door/panel movement several times to ensure smooth operation

This clutch assembly is a genuine OEM replacement part sourced directly from the manufacturer and is intended for use in washing machines. The clutch assembly controls the movement of the internal tub and agitator during operation. Over time and with regular use, the clutch assembly may become worn and fail to work correctly. If the washing machine tub is not moving back and forth during the wash cycle or is not spinning during the spin cycle, the clutch is broken. If it is moving or spinning, but not efficiently or fast enough, the clutch is worn and beginning to fail. In both of these instances, the clutch assembly should be replaced. Excessively wet clothes at the end of the laundry cycle can also be indicative of a broken clutch.A screwdriver, socket set, putty knife, and impact wrench with a large 38mm socket are required to make this replacement. Ensure the power is disconnected and the machine is drained. While the tub is out of the machine, take time to clean the area of gunk and buildup. Wear gloves while working on the machine.This clutch assembly is made of durable metals and is individually sold. It is designed for use in washing machines by LG and Kenmore.

The Water Inlet Valve is an OEM replacement part specific to LG washing machines. It is an electronic solenoid valve located near the water supply inlet ports that controls the flow of water into the washer tub. The inlet valve precisely regulates water levels during different phases like filling, washing, rinsing, and spinning cycles.

Causes of a bad water inlet valve can include worn or faulty electronic components, mineral buildup obstructing valve movement, or damage to seals and diaphragms.

Symptoms of a bad water inlet valve include:

• Inability to properly fill the washer tub during cycles
• Water leaking or flooding from the valve area
• Erratic water temperature or varying fill levels between loads
• Cycles failing to advance due to inadequate or unregulated water flow

This OEM LG part is also compatible with Sears/Kenmore models.

Detergent housing assembly that holds and routes detergent to the washer dispenser, helping ensure proper detergent flow and reducing leaks or dispenser jams. Fits into the dispenser area to replace cracked, warped, or damaged housing components. What it does:

• Houses and channels liquid or powdered detergent into the dispenser and wash chamber
• Restores proper detergent release when the original housing is cracked, broken, or warped
• Helps stop leaks and detergent buildup around the dispenser area
• Works with the dispenser drawer and related seals to maintain correct flow

• Disconnect power and turn off the water supply before starting service
• Use basic hand tools and follow the washer service manual or OEM diagram for disassembly/reassembly
• Inspect and replace any worn seals or gaskets at reassembly to prevent leaks

The Stator Assembly is an OEM replacement part for LG washing machines. It is an electrical component inside the motor that converts rotational motion to electrical energy to power spinning motions.  Note: For the RPS or Hall Sensor, order part number AP7015078.

Symptoms of a faulty stator include:

• Slow or inefficient spinning, rubbing noises
• The machine failing to fully drain or spin clothes
• Repeated blowouts or failure of related motor components

Causes can be wear and tear over extended use. Environmental factors like dust and moisture exposure may degrade insulation integrity.

This OEM stator is also compatible with some Kenmore front-load washer models.

The Water Level Pressure Switch is an OEM replacement part for LG washing machines. It is an essential component that monitors and detects the water level within the washing machine tub during the wash cycle.

Symptoms of a bad water level pressure switch:

• Washing machine not filling with water or not stopping when the desired water level is reached
• Excessive water intake, leading to overfilling and potential leaks
• Error codes or indicators related to water level issues
• Washing machine not advancing to the next cycle due to incorrect water level detection

Causes of a bad water level pressure switch can include mechanical failure, electrical malfunctions, or blockages or debris preventing accurate water level readings.

This OEM LG part is also compatible with Sears/Kenmore washing machine models.

A standard replacement bolt used to secure appliance panels and internal assemblies. This OEM-style fastener restores proper fit and reduces movement that can cause noise or misalignment in appliance components. What it does:

• Fastens panels, brackets, and components to maintain structural integrity
• Keeps moving parts aligned to help prevent rattling or vibration
• Replaces missing, loose, or corroded bolts that compromise fit
• Suitable where a standard machine/sheet-metal bolt is required

• One bolt

• Disconnect power and water before servicing the appliance
• Use the correct driver/socket to avoid stripping the head or threads
• Tighten securely but avoid over-torquing; replace any damaged nuts or washers
• Inspect mating threads and clean or chase threads if corroded

The Clutch Motor is an OEM part for LG washing machines. This motor engages the clutch mechanism, allowing the washer to switch between agitating and spinning cycles effectively.

Causes of a bad clutch motor can include wear and tear over time, electrical issues, or mechanical failure due to overloading or improper use.

Symptoms of a bad clutch motor include:

• The washer not agitating or spinning
• Unusual noises during the wash or spin cycles
• The drum not rotating properly
• The washer stopping mid-cycle

This OEM LG part is also compatible with Sears/Kenmore models.

This multi wiring harness routes power and signals between the appliance control and multiple components to restore reliable electrical connections. It replaces a damaged or worn multi-connector harness so parts receive proper power and communication. What it does:

• Carries power and signal lines between the main control and connected components.
• Restores connections to parts when broken, pinched, or corroded wiring causes intermittent or no operation.
• Helps resolve symptoms such as components not powering, intermittent failures, or control/communication errors.
• Provides factory-style connectors for a direct fit where specified by the manufacturer.

• One multi wiring harness as shown.

• Disconnect all power before beginning work to avoid shock or injury.
• Document connector locations and/or take photos before removal to ensure correct reassembly.
• Route the harness away from heat, sharp edges, and moving parts; secure with existing clips or ties.
• Verify all connectors are fully seated and locked before restoring power; test the appliance after installation.

This multi wire harness routes power and signals between appliance components to restore reliable electrical connections. It replaces a damaged or worn wiring harness to help resolve intermittent power, unresponsive controls, or component failures. What it does

• Connects multiple circuits and plugs to link controls, sensors, and motors.
• Restores lost or intermittent electrical connections caused by frayed wires or broken terminals.
• Helps eliminate faults such as intermittent power, non-working controls, or components that don't respond.
• Maintains correct routing and connector mating to prevent shorting or signal errors.

• Disconnect power (unplug or shut off circuit breaker) before starting any work.
• Note connector locations and routing before removing the old harness; take photos if helpful.
• Match each connector by shape and color; do not force connectors together.
• Secure harness away from sharp edges, moving parts, and heat sources; replace any damaged clips or retainers.

Replacement nut that secures drawer and trim components on compatible LG appliances. It restores a firm, vibration-resistant fastening to help prevent loosening, rattling, or misalignment during normal use. What it does:

• Secures drawer, trim or small mounting brackets to the appliance chassis.
• Helps stop loosened fasteners that cause rattling or misaligned panels.
• Provides proper thread engagement for a stable connection.
• Matches the appliance's original fastening point when used as the listed part.

• Always disconnect power to the appliance before beginning any repair.
• Use the correct-size wrench or socket; avoid overtightening to prevent stripped threads.
• Inspect mating screw/bolt and threads for damage; replace damaged hardware as needed.

This is a small OEM washer used with the washer's internal mounting hardware to provide proper spacing and secure fasteners. It helps keep assemblies aligned and prevents hardware from loosening during operation. What it does:

• Acts as a spacer and load distributor for bolts or screws in the washer assembly
• Helps maintain proper alignment of panels or components
• Reduces wear between mating metal parts
• Can prevent fasteners from backing out due to vibration

• One washer as pictured

• Always unplug the appliance and shut off the water supply before servicing
• Access the mounting location per the service manual or parts diagram; replace only like-for-like
• Install with the correct orientation and hardware; do not overtighten fasteners
• If other fasteners or parts are corroded or worn, replace them at the same time

Kit is no longer available. Order MCJ61861201 and ACP72929002 separately.

The Dispenser Assembly is an OEM part for LG washing machines. This part dispenses the appropriate amounts of detergent, fabric softener, or other laundry additives at the right time during the wash cycle.

Causes of a bad Dispenser Assembly can include clogging or buildup of residue, damage to the dispensing mechanisms or components, or issues with the electronic controls that regulate the dispensing process.

Symptoms of a bad washer Dispenser Assembly include:

• Improper dispensing of detergent or fabric softener
• Leaks or drips from the dispenser area
• The dispenser drawer not opening or closing properly
• Failure of the dispenser to dispense at the correct time during the cycle

This OEM LG part is also compatible with some Kenmore models.

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.
