Parts for Magic Chef CYG4000AWA: 03 - Tumbler Parts

Specs: 10-16 x 1/2 inch.

This motor pulley transfers power from the drive motor to the washer belts. The 60 Hz sizing restores the correct speed and belt tracking so the tub agitates and spins smoothly without squeal or slippage. What it does:

• Drives the belt(s) that power the washer's drive system (and on some models, the drain pump)
• Maintains the correct speed ratio for 60 Hz operation
• Worn or damaged pulley can cause belt squeal, burning rubber odor, or frayed/slipping belts
• Result in no/slow spin or agitation if the belt can't grip properly

• One motor pulley (60 Hz)

• Disconnect power before servicing; wear cut-resistant gloves
• Access the motor, relieve belt tension, and note belt routing
• Loosen the pulley set screw and remove the old pulley from the motor shaft
• Install and align the new pulley; adjust belt alignment/tension per service information, hand-rotate to check clearance, then test

• Designed for 60 Hz electrical systems; match the Hz rating to your original part

Specs: 10-16 x 1/2 inch.

This part is a motor clamp. This is a genuine OEM part and has been sourced directly from the manufacturer. This part is intended to replace a deteriorated, damaged, or broken motor clamp on certain makes of indoor appliance models. Motor clamps are essential for properly securing the drive motor on various types of indoor appliances such as washers, dryers, and refrigerators. Without the use of a motor clamp, the drive motor is free to move around or become detached. This can easily cause serious damage to the equipment and prevent proper functionality. Proper tools are needed to replace this part and appropriate safety measures should be adhered to when working on any type of equipment. For accurate information on how and where to install this replacement motor clamp, specific manufacturer diagrams should be referred to.As an authentic replacement part, this motor clamp can be used on multiple different models of washers, dryers, refrigerators, and washer/dryer combos manufactured by Kenmore, Maytag, Whirlpool, and Amana. Please note that this motor clamp is a genuine part made of high-quality materials and is sold individually.

This idler assembly is the spring-loaded belt tensioner that keeps the drive belt correctly tightened. Replacing a worn or seized idler restores smooth belt tracking, reduces squeal, and helps prevent slippage or loss of drive.

• Maintains proper tension on the drive belt for reliable power transfer
• Helps prevent belt slippage, squealing, or the belt coming off the pulleys
• Supports smooth rotation of the driven components
• Failure symptoms can include noise from the belt path, a frayed or derailed belt, or loss of motion

• Disconnect power and allow all moving parts to stop before servicing
• Access the belt path; relieve belt tension and remove the old idler assembly
• Install the new assembly; ensure the pulley spins freely and the belt is centered in the groove
• Manually rotate the system to verify alignment and clearances before restoring power

This idler spring maintains proper tension on the dryer drum belt by keeping the idler pulley engaged. Replacing a weak or broken spring restores consistent drum rotation and helps prevent belt slippage and squealing during operation.

• Maintains belt tension by pulling the idler arm/pulley against the drum belt
• Helps the motor start and keep the drum turning smoothly
• Reduces belt slippage that can cause squealing or chirping
• Common symptoms of a failed spring: drum won't turn or turns intermittently; belt comes off or feels loose; loud squeal from idler area

• Disconnect power; for gas dryers, shut off the gas supply
• Access the idler assembly; relieve belt tension and note belt/spring routing before removal
• Attach the new spring to the same holes/orientation on the idler arm and base; verify belt path
• Rotate the drum by hand to confirm alignment and tension before reassembly

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Replace a damaged collector duct to restore proper ventilation airflow. This kit channels air from the appliance's intake to the exhaust path, helping reduce leaks, noise, and recirculation for consistent capture performance.

• Directs airflow from the intake/collector to the exhaust duct path
• Helps maintain proper airflow and capture efficiency
• Provides a sealed transition to minimize air leaks and recirculation
• Common symptoms: poor vent suction, smoke/steam lingering, rattling vibrations, visible damage or gaps

• Disconnect power at the breaker; shut off gas before servicing
• Wear cut-resistant gloves—sheet-metal edges can be sharp
• Note airflow orientation and gasket locations; dry-fit before fastening
• Seal joints with UL-listed foil HVAC tape; do not use cloth duct tape

The Blower Wheel is an OEM part for Whirlpool dryers. It is essential for circulating air through the dryer's drum, helping to efficiently and evenly dry clothes by moving heated air past the tumbling laundry. This component is crucial for maintaining the performance and energy efficiency of your dryer.

Symptoms of a bad Blower Wheel include:

• Unusual noises, such as rattling or thumping, indicating a loose or damaged wheel.
• Reduced airflow, leading to longer drying times or clothes not drying completely.
•  Excessive vibrations during operation, which can also affect other components.

Causes of a bad blower wheel can include physical damage from foreign objects hitting the wheel, wear and tear from regular use, or accumulation of lint and debris that unbalances the wheel.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Clamp is an OEM part for Whirlpool dryers. This clamp ensures tight and secure connections within the dryer, particularly in securing ducts and vents that are essential for proper airflow and operation.

Clamps may need replacement due to loss of tension, corrosion, or damage from regular use. A compromised clamp can lead to operational issues such as prolonged drying times or excessive noise, resulting from loose parts or improper ventilation.

Symptoms of a bad Clamp include:

• Loose or detached vents or hoses, leading to inefficient dryer operation.
• Increased drying times, as a result of compromised airflow from unsecured ducts.
• Unusual vibrations or noise, indicating that internal components may not be securely fastened.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Can use 410233

This replacement cabinet screw secures panels, brackets, and ducts in Whirlpool-built appliances so components stay aligned and secure. Replacing missing or stripped hardware helps reduce vibration, rattling, and gaps that can affect performance.

• Fastens panels, brackets, and internal components in the appliance cabinet
• Helps maintain proper alignment and reduce vibration or rattling noises
• Restores a tight fit where original hardware is missing, damaged, or stripped
• Typical symptoms: loose paneling, buzzing/rattling sounds, or parts that won't stay fastened

• Disconnect power; for gas models, also shut off the gas supply
• Replace one fastener at a time to preserve alignment and match to the original hardware
• Use the correct driver; start threads by hand to avoid cross-threading
• Do not overtighten into sheet metal

This cycling thermostat regulates on/off heat cycles to maintain consistent operating temperature. Replacing a failed thermostat restores proper temperature control and helps protect the appliance from overheating or underheating during normal operation.

• Senses internal temperature and opens/closes contacts to control the heating circuit
• Helps prevent overheating; supports stable, repeatable heat cycling
• Common failure symptoms include no heat, overheating/shutting off too soon, or longer-than-normal run times
• Electrical component—failure may be intermittent before complete loss of function

• Disconnect power (and gas supply, if applicable) before service
• Note wire locations; transfer connectors one at a time to the new thermostat
• Mount firmly against the mating surface for accurate temperature sensing
• After installation, verify proper operation and temperature cycling

This idler assembly is the spring-loaded belt tensioner that keeps the drive belt correctly tightened. Replacing a worn or seized idler restores smooth belt tracking, reduces squeal, and helps prevent slippage or loss of drive.

• Maintains proper tension on the drive belt for reliable power transfer
• Helps prevent belt slippage, squealing, or the belt coming off the pulleys
• Supports smooth rotation of the driven components
• Failure symptoms can include noise from the belt path, a frayed or derailed belt, or loss of motion

• Disconnect power and allow all moving parts to stop before servicing
• Access the belt path; relieve belt tension and remove the old idler assembly
• Install the new assembly; ensure the pulley spins freely and the belt is centered in the groove
• Manually rotate the system to verify alignment and clearances before restoring power
